CM3-U3-28S4C-CS

Chameleon3 USB3

Chameleon3 USB3

Model :CM3-U3-28S4C-CS : (Discontinued)

Featured Information

Part Number :

CM3-U3-28S4C-CS

Resolution :

1928 × 1448

Frame Rate :

Chameleon3 USB3

SPECIFICATIONS

Part Number : CM3-U3-28S4C-CS
Resolution : 1928 × 1448
Frame Rate : 13
Megapixels : 2.8
Chroma : Color
Sensor Name : Sony ICX818
Sensor Type : CCD
Sensor Format : 1/1.8
Readout Method : Global shutter
Pixel Size : 3,69

Trigger Modes : Standard, bulb, low smear, overlapped, multi-shot
User Sets : 2 user configuration sets for custom camera settings

PHYSICAL

ADC : 12-bit
Auxiliary Output : 3.3 V, 150 mA maximum
Chroma : Color
Dimensions [W x H x L] : 44 mm × 35 mm × 19.5 mm (case enclosed); 40 mm × 31 mm (board level)
Interface : USB 3.1 Gen 1
Lens Mount : CS-mount (5 mm C-mount adapter not included)
Mass : 54.9 grams
Megapixels : 2.8
Non-isolated I/O Ports : 2 bi-directional
Operating Humidity : 20 to 80% (no condensation)

Storage Humidity : 20 to 95% (no condensation)
Storage Temperature : -30° to 60°C

COMPLIANCE & CERTIFICATIONS

Compliance : CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099.
Machine Vision Standard : USB3 Vision v1.0
Warranty : 3 years

Lens Mount : CS-mount (5 mm C-mount adapter not included)
ADC : 12-bit
Required Accessories : Lens, Cable, Host Adapter (USB 3.1 Gen 1), Tripod Mount Adapter (ACC-01-0003)
Exposure Range : 0.064 ms to 31.9 seconds
Flash Memory : 1 MB non-volatile memory
Frame Rate : 13
Gain Range : -8.341 dB to 23.991 dB (Remove parameter limit to enable negative gain)
Image Buffer : 16MB
Image Processing : Gamma, lookup table, hue, saturation, and sharpness
Partial Image Modes : Pixel binning, decimation, ROI

PERFORMANCE

Absolute Sensitivity Threshold (y) : 20.00
Dynamic Range dB : 59.03
Quantum Efficiency Blue : 51 (% at 470 nm)
Quantum Efficiency Green : 54 (% at 525 nm)
Quantum Efficiency Red : 48 (% at 640 nm)
Saturation Capacity (e-) : 9462
Temporal Dark Noise (e-) : 10.08

Operating Temperature : 0° to 45°C
Opto-isolated I/O Ports : 1 input, 1 output
Part Number : CM3-U3-28S4C-CS
Pixel Size : 3,69
Power Requirements : 5-24 V via GPIO or 5 V via USB3
Readout Method : Global shutter
Resolution : 1928 × 1448
Sensor Format : 1/1.8
Sensor Name : Sony ICX818
Sensor Type : CCD

RECOMMENDED SYSTEM CONFIGURATION

CPU : 3.1 GHz or equivalent CPU
Hard Drive : 200 MB hard drive space
Operating System : Windows or Linux (32–bit or 64–bit)
Port : USB 3 Port
RAM : 2 GB RAM or more
Required Accessories : Lens, Cable, Host Adapter (USB 3.1 Gen 1), Tripod Mount Adapter (ACC-01-0003)

CM3-U3-28S4C-CS

Chameleon3 USB3

The Chameleon®3 camera family combines the ease-of-use of USB3, small size, flexibility of board-level versions, and popular CCD and CMOS image sensors into an affordable package. For FLIR cameras with the latest sensors and most advanced feature sets, please refer to Blackfly S and Oryx camera families.
