Genie Nano-CXP M5100-NIR

MORE PIXELS, MORE PERFORMANCE, SAME NANO QUALITY

MORE PIXELS, MORE PERFORMANCE, SAME NANO QUALITY

Model :Genie Nano-CXP M5100-NIR

Featured Information

Part Number :

G3-XM32-M5105

Resolution :

5120 x 5120 On-Semi Python 25K

Spectrum :

Mono, NIR

MORE PIXELS, MORE PERFORMANCE, SAME NANO QUALITY

Features :

Part Number : G3-XM32-M5105
Resolution : 5120 x 5120 On-Semi Python 25K
Spectrum : Mono, NIR
Interface : CoaXPress
Pixel Size : 4.5 µm
Max Frame Rate : 80 fps
Total Pixels : ~ 26,2 MP
Interface Speed : 25 Gbps
Operating Temperature : -20—60 °C
Dynamic Range : 55 dB

Shutter Type : Global Shutter
Dimensions (W x H x L) : 32x59x59mm
Mass : 163 g

Genie Nano-CXP M5100-NIR

MORE PIXELS, MORE PERFORMANCE, SAME NANO QUALITY

Genie Nano CXP Family Datasheet

Introducing Genie Nano-CXP, a camera designed for full-throttle performance. Genie Nano-CXP builds on Nano's proven, industry leading reputation and leverages a CoaXPress 6Gbps interface to deliver the maximum throughput from leading edge high resolution CMOS image sensors.
