FLIR ITS-Series
320 x 256, 17 ° FOV
FLIR ITS-Series
320 x 256, 17 ° FOV
Model :FLIR ITS317
Featured Information
Analog Video Output :
NTSC, PAL or PAS 8.3Hz
Video Over Ethernet :
Two independent channels of H.264 or M-JPEG
FLIR ITS317
320 x 256, 17 ° FOV
COMMUNICATIONS
- Analog Video Output : NTSC, PAL or PAS 8.3Hz
- Video Over Ethernet : Two independent channels of H.264 or M-JPEG
ENVIRONMENTAL
- Humidity : 0-95% relative humidity
- IP Rating : IP66 & IP67
- Operating Temperature Range : -50° to 70°C (-58° to 158°F) continuous operation -40° to 70°C (-40° to 158°F) cold start
- Shock : MIL-STD-810G
- Standard Package : Thermal imaging camera, operator manual
- Storage Temperature Range : -50° to 85°C (-58° to 185°F)
- Vibe : IEC 60068-2-27
- Surge Immunity on AC Power Lines : EN 55024: 2010 and 55022: 2010 to 4.0kV on AC aux power lines; EN 50130-4:2011; IEC 62599-2:2010
REGULATORY
- Approvals : CE: EN55022 Class A; FCC 47 CFR Part 15, Subpart B, Class A (within CISPR 22:2008 Class A limits)
ELECTRICAL
- Power Consumption - Source – 12VDC : Heater off: <5.5 W Heater on (at 100%): <25 W
- Power Consumption - Source – 24VAC(VA) : Heater on: <8 W Heater off (at 100%): <32 W
- Power Consumption - Source – 24VDC : Heater on: <5.5 W Heater off (at 100%): <25 W
- Power Consumption - Source – POE+ [802.3at] : Heater on: <5.5 W Heater off (at 100%): <25 W
- Surge Immunity on Signal Lines : EN 55024:2010 and 55022:2010 to 4.0kV
IMAGING & OPTICAL
- Automatic Heater : Clears ice from windows, Automatic deicing
- Detector Type : Focal Plane Array (FPA), uncooled VOx microbolometer
- Field of View : 17° x 14°
- Image Processing : Automatic Gain Control (AGC), Digital Detail Enhancement (DDE)
- Resolution : 320 x 256
- Spectral Range : 7.5 to 13.5 µm
FLIR ITS-Series sensors deliver superior image accuracy and reliability for traffic monitoring applications. ITS-Series thermal imaging sensors can monitor vehicles in a wider variety of conditions than traditional visible-light sensors. By detecting the heat of all objects in the scene, the FLIR ITS-Series operates in broad daylight or total darkness, poor weather and even light fog. Combined with FLIR’s video analytics boards, the FLIR ITS-Series makes a great solution for Automatic Incident Detection (AID).
