Model :BFS-U3-200S6C-BD2: 20 MP, 17 FPS, Sony IMX183, Color

Featured Information

Part Number :
BFS-U3-200S6C-BD2
Resolution :
5472 × 3648
Frame Rate :
17
Product thumb
BFS-U3-200S6C-BD2: 20 MP, 17 FPS, Sony IMX183, Color
Blackfly S Board Level

SPECIFICATIONS

  • Part Number :  BFS-U3-200S6C-BD2
  • Resolution :  5472 × 3648
  • Frame Rate :  17
  • Megapixels :  20
  • Chroma :  Color
  • Sensor Name :  Sony IMX183
  • Sensor Type :  CMOS
  • Sensor Format :  1
  • Readout Method :  Rolling shutter with global reset
  • Pixel Size :  2.4

FEATURES

  • Acquisition Modes :  Continuous Single Frame Multi Frame
  • Exposure Range :  11 µs to 30 seconds
  • Flash Memory :  6 MB non-volatile memory
  • Frame Rate :  17
  • Gain Range :  0 dB to 27 dB
  • Image Buffer :  240 MB
  • Image Processing :  Color correction matrix, gamma, lookup table, saturation, and sharpness
  • Partial Image Modes :  Pixel binning, ROI
  • User Sets :  2 user configuration sets for custom camera settings

PHYSICAL

  • ADC :  10-bit, 12-bit
  • Auxiliary Output :  3.3 V, 120 mA maximum
  • Chroma :  Color
  • Dimensions [W x H x L] :  29 mm × 29 mm × 10 mm
  • Interface :  USB 3.1 Gen 1
  • Lens Mount :  Lens mount sold separately
  • Mass :  10 grams
  • Megapixels :  20
  • Non-isolated I/O Ports :  4 bi-directional
  • Operating Humidity :  20 to 80% (no condensation)

  • Storage Humidity :  30 to 95% (no condensation)
  • Storage Temperature :  -30° to 60°C

UYUMLULUK VE SERTİFİKALAR

  • Uyma :  CE, FCC, RoHS. Bu ürün için ECCN: EAR099.
  • Yapay Görme Standardı :  USB3 Vision v1.0
  • Garanti :  3 yıl

  • Lens Mount :  Lens mount sold separately
  • ADC :  10-bit, 12-bit
  • Required Accessories :  Lens mount and lens, cable, host adapter (USB 3.1 Gen 1), TF38 to FPC USB3 panel mount adapter, heatsink (recommended)

PERFORMANCE

  • Absolute Sensitivity Threshold (y) :  5.54
  • Dynamic Range dB :  71.95
  • Quantum Efficiency Blue :  63 (460 nm)
  • Quantum Efficiency Green :  68 (530 nm)
  • Quantum Efficiency Red :  43 (625 nm)
  • Saturation Capacity (e-) :  15012
  • Temporal Dark Noise (e-) :  3.29

  • Operating Temperature :  0° to 50°C
  • Part Number :  BFS-U3-200S6C-BD2
  • Pixel Size :  2.4
  • Power Consumption [Maximum] :  3 W
  • Power Requirements :  5 V via USB 3.1 interface
  • Readout Method :  Rolling shutter with global reset
  • Resolution :  5472 × 3648
  • Sensor Format :  1
  • Sensor Name :  Sony IMX183
  • Sensor Type :  CMOS

RECOMMENDED SYSTEM CONFIGURATION

  • CPU :  3.1 GHz or equivalent CPU
  • Hard Drive :  200 MB hard drive space
  • Operating System :  Windows or Linux (32–bit or 64–bit)
  • Port :  USB3 Port
  • RAM :  2 GB RAM or more
  • Required Accessories :  Lens mount and lens, cable, host adapter (USB 3.1 Gen 1), TF38 to FPC USB3 panel mount adapter, heatsink (recommended)

Product thumb
BFS-U3-200S6C-BD2: 20 MP, 17 FPS, Sony IMX183, Color
Blackfly S Board Level

The FLIR Blackfly S Board Level variants are high performance, machine vision, area scan cameras designed for embedding into tight spaces. Unlike many board level cameras, it boasts a rich feature set applied to the latest CMOS sensors; the same feature set as the cased version. It is ready for integration with proven compatibility with popular SBCs and SOMs. The Blackfly S board level models enable OEMs to develop smaller, lighter, and lower cost solutions with embedded system connectivity and rich features.
