FLIR MD625

Compact Fixed View Marine Thermal Camera

FLIR MD625

Compact Fixed View Marine Thermal Camera

Featured Information

Field of View :

25° × 20° (NTSC)

Resolution :

640 x 480

Size :

6" dia. × 7" ht.

FLIR MD625

Compact Fixed View Marine Thermal Camera

GENERAL

Field of View : 25° × 20° (NTSC)
Resolution : 640 x 480
Size : 6" dia. × 7" ht.
Standard Package : Camera Head with ~5"of Cable, Analog Video, and Ethernet (PoE powered device); Operator Manual CD
Detector Type : 640 × 480 VOx Microbolometer
Focal Length : 25 mm
Weight : ~ 3 lbs

CONNECTIONS & COMMUNICATIONS

Construction Type : F-type BNC with BNC-to-RCA adapter included for video out
Video Output : NTSC or PAL, 30 Hz or <9Hz

ENVIRONMENTAL

Automatic Window Defrost : Standard at Power-Up
Temperature (Operating) : -25°C to +55°C
Lightning Protection : Standard
Sand & Dust : Mil-Std-810E
Storage Temperature Range : -40°C to +85°C
Salt Spray : IEC 60945
Shock : 15 g vertical, 9 g horizontal
EMI : IEC 60945
Vibration : IEC 60945; MIL-STD-810E
Wind : 100 knot (115.2 mph)

PAN-TILT FEATURES

Pan Range : ±30° per key (Locked in at Installation)
Tilt Range : +34°, -27° (Locked in at Installation)

IMAGING & OPTICAL

E-Zoom : 2×, 4×
Image Processing : FLIR Proprietary Digital Detail Enhancement

POWER

Power : PoE injector required per IEEE 802.3af
Power Consumption : 4.8 W nominal; 12.5 W max

FLIR MD625

Compact Fixed View Marine Thermal Camera

The MD-Series is an affordable, compact fixed-mounted thermal night vision system that helps with steering around obstacles, collision avoidance, and finding people in the water at night. Simple to mount and easy to integrate into your existing electronics, MD-Series outputs standard analog video that can be easily displayed on almost any monitor at the helm or other locations on the vessel.
