TRK-101

Analytics Encoder

TRK-101

Analytics Encoder

Featured Information

Dimensions (inches) :

2,7 x 1,42 x 4,61

Dimensions (mm) :

68,5 x 36 x 118 mm (G x Y x D)

TRK-101

Analytics Encoder

Dimensions (inches) : 2,7 x 1,42 x 4,61
Dimensions (mm) : 68,5 x 36 x 118 mm (G x Y x D)
H.264 Frame Rate (PAL/NTSC) : D1 12/15 FPS VGA 18 FPS 2CIF 25/30 FPS CIF 25/30 FPS
Number of Intelligent Video Analysis Channels : 1
Power Consumption : DC: 3.6W, AC: 6W
Operating System : Windows 7, 8 ve 8.1, 10
Alarms/Commands : TCP/IP, HTTP
Ethernet (IEEE 8023-8023u) : 1 x RJ45 interface
Services and Protocols : TCP/IP, UDP/IP, HTTP, SMTP, DHCP, DNS, SNTP

TRK-101

Analytics Encoder

The TRK-101 analyzes video signals and sends alarm notifications when people, vehicles and objects cross perimeter lines, enter pre-defined regions, or are left behind or removed from a scene. Users can define perimeters and customize what to detect. The TRK-101 has both analog and IP streaming video outputs that enable hybrid connectivity to both legacy and IP-based CCTV networks. The encoder also integrates with existing fixed analog cameras for retrofit of existing installations.
