FLIR Vue TZ20
High resolution gimbalized dual thermal zoom payload
FLIR Vue TZ20
High resolution gimbalized dual thermal zoom payload
Featured Information
Airframe Compatibility :
DJI V2 Matrice 200-series and Matrice 300
Ground Control :
DJI Pilot App
FLIR Vue TZ20
High resolution gimbalized dual thermal zoom payload
AIRCRAFT
- Airframe Compatibility : DJI V2 Matrice 200-series and Matrice 300
- Ground Control : DJI Pilot App
ENVIRONMENTAL & APPROVALS
- Environmental Sealing : IP44
- Operational & Storage Temperature : Operational: -20° to 45°C (-4° to 113°F) Storage: -20° to 60°C (-4° to 140°F)
- Tested EMI Performance : FCC part 15 Class B
IMAGING & OPTICAL
- IR Camera Optics : Wide FOV: 95° HFOV, 4.9 mm EFL Narrow FOV: 18° HFOV, 24 mm EFL
- IR Camera Resolution : 2 FLIR Boson 640 × 512
- Radiometric Features : Spot meter, measurement box with min/max/avg Isotherms above or below threshold temperature
- Streaming Video : 640 × 512 @ 25 Hz
MECHANICAL
- Mechanical Interface : Skyport 2.0 connector, X-Port DJI gimbal
THERMAL CAMERA
- Pixel Pitch : 12 µm LWIR
ELECTRICAL
- Electrical Interface : Skyport 2.0, 13.6V/2A
GIMBAL
- Gimbal Range of Motion : 3-axis Pitch: 30° to -120° Yaw: ±270°
MEASUREMENT & ANALYSIS
- Thermal Sensitivity : 85 mK @ F/1.0
RADIOMETRY
- Radiometric Accuracy : Accuracy: ±5C / 5% for scenes +10C to +100C Scene dynamic range: -10C to +300C
VIDEO & RECORDING
- Recording : Still: Radiometric JPEG, raw TIFF Periodic capture 1s – 30s interval, all still image formats Video MPEG 25Hz (zoomed) Radiometric CSQ 5Hz (zoomed) Raw multipage TIFF 10Hz (wide and narrow FOV separate)
FLIR Vue TZ20
High resolution gimbalized dual thermal zoom payload
The dual-Boson® FLIR Vue® TZ20 plug-and-play payload is designed to improve mission success and is fully integrated with the DJI V2 Matrice 200-series and 300 airframes. This system provides a wide 95-degree field of view for maximum situational awareness and a narrow 18-degree field of view to put more pixels on target when needed. With 20X zoom capabilities, the FLIR Vue TZ20 allows drone pilots from the public safety and industrial inspection sectors to gain field of view flexibility for improved image detail and magnification to assess situations and make critical decisions.
