FLIR CM-6408
GENERAL
- Automatic Electronic Shutter [AES] : 1/1 to 1/32,000 (auto)
- Day/Night Mode : Yes
- Digital Slow Shutter [DSS] : 1/1(1)~1/60(50) NTSC(PAL)
- Dimensions : 161x128.6 mm (6.3 x 5 in.)
- Enclosure : Indoor/Outdoor: IK10 rated vandal IP66
- Firmware Upgrade : Flash memory for upgrade of camera firmware over the network
- Input Voltage : PoE IEEE802.3af, class 0 AC24V, max 13.68 watt
- Power Connection : RJ45 & 24VAC
- Power Consumption : 12.5W with heater and IR
- Privacy Zones : Yes
COMPLIANCE & CERTIFICATIONS
- International : CE marked, EN61000-6-3 & EN50130-4, RoHS, RCM*
- ONVIF : Profiles S, G & T
- USA UL, FCC Part 15 (subpart B, class A)
ENVIRONMENTAL
- Humidity : 90% (non-condensing)
- Operating Temperature : -30°C~60°C (-22°F~140°F) without heater -55°C~60°C (-67°F~140°F) with heater Cold start -40°C~60°C (-40°F~140°F) with heater
- Storage Temperature : -20°C~70°C (-4°F~158°F)
PTZ
- Pan_Tilt_Spin : 356° / ±80° / ±98°
VIDEO & RECORDING
- Maximum Performance : H.264/H.265 30/25 FPS @ 4K (NTSC/PAL) + 30/25 FPS @ D1 or H.264/H.265 15/12 FPS @ 4K + 1080P + D1 (NTSC/PAL) or H.264/H.265 60/50 FPS @ 1080P + 30/25 FPS @ 720P + D1 (NTSC/PAL)
- Rate Control : CBR, CVBR, LBR, MJPEG
- Resolution Range : Scalable from QCIF to 4K
- SD Card Recording1 : microSD/microSDHC/microSDXC 8GB to 512GB (Class 10)
- Video Motion Detection : Yes
- Scanning Mode : Progressive
- Shutter WDR : 130dB
- Tamper Detection : Yes
- Warranty : According to FLIR RMA Policy and Process Notice document
- Power Consumption : 12.5W with heater and IR
CYBER SECURITY
- Security : Password protection, IP address filtering, TLS/HTTPS, IEEE 802.1X network access control, Digest authentication Password policy Protect from multiple failure login
MEASUREMENT & ANALYSIS
- Automatic Gain Control : Auto
SYSTEM INTEGRATION
- Bi-directional Audio : 1 Audio Line Input, G.711 a/µ-law, AAC support + 1 Audio Line Output
- Distance : Up to 40m (131 ft.) Sunshield 28m (91.8 ft.)
- Ethernet : 10/100/1000, IEEE 802.3, auto sensing 1 x RJ45
- Input : 1 dry alarm contact 1 5V 10kΩ pull up
- Network Protocol : IPV4/6, HTTP, HTTPS, ,UPnP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X, SNMP,QoS, TLS, SMTP, FTP, DDNS, PPPoE, RTCP
- Output : 1 Relay Contact max. DC 5V 130MA
- Peak Emission Wavelength [nm] : 850
- Remote Configuration : Via web browser or supported video management software
- Supported Web Browser : Internet Explorer, Firefox, Chrome, Edge, Safari
VISIBLE CAMERA
- Backlight Compensation : On / Off
- Bandwidth : Confgurable between 64Kbps and 20Mbps
- USA UL, FCC Part 15 (subpart B, class A)
- Lens Type : Varifocal 4.46-11mm, 40.43°- 110.76° HFOV, 22.65°-57.14° VFOV, F1.47-F2.5, D/N, Zoom, Auto-Focus / Auto-Iris, P-Iris
- Mechanical IR Cut Filter : Yes
- Noise Reduction : 3D/2D/Color
- Sensitivity : 0.04 (color)/0.002 (BW), 0 Lux with IR illuminator ON, measured at 30 IRE
- Sensor Resolution : 3864×2180
- Signal to Noise Ratio : ±50 dB
- White Balance : Auto / ATW / Manual / One Push
FLIR CM-6408
The FLIR Quasar premium mini-dome camera was designed to provide situational awareness in the most demanding environments, where evidential and forensic video is required. It is offered in a 5MP HD and 4k UHD variant, delivering superior image quality and IR-Illumination for exceptional performance using low bandwidth. Ideal for critical infrastructure sites, remote facilities, or any large requiring close monitoring, the Quasar premium mini-dome is a discreet surveillance option that is NDAA-compliant and utilizes high-end cybersecurity safeguards. Ease of installation, FLIR accessory/mounting ecosystem, and the ability to operate more cameras on the same server all contribute to a lower total cost of ownership. It offers seamless integration with a wide range of video management systems, including United VMS, which brings indoor and outdoor surveillance and perimeter intrusion detection cameras together as part of an end-to-end security solution.
