Blackfly S USB3

Blackfly S USB3

Model :BFS-U3-04S2M-CS: 0,4 MP, 522 FPS, Sony IMX287, Mono

Featured Information

Part Number

BFS-U3-04S2M-CS

Resolution

720 × 540

Frame Rate

522

BFS-U3-04S2M-CS: 0,4 MP, 522 FPS, Sony IMX287, Mono

Blackfly S USB3

SPECIFICATIONS

Part Number BFS-U3-04S2M-CS
Resolution 720 × 540
Frame Rate 522
Megapixels 0.4
Chroma Mono
Sensor Name Sony IMX287
Sensor Type CMOS
Sensor Format 1/2.9
Readout Method Global shutter
Pixel Size 6.9

User Sets : 2 user configuration sets for custom camera settings

PHYSICAL

ADC : 8-bit, 10-bit, 12-bit
Auxiliary Output : 3.3 V, 120 mA maximum
Chroma : Mono
Dimensions [W x H x L] : 29 mm × 29 mm × 30 mm
Interface : USB 3.1 Gen 1
Lens Mount : CS-mount
Mass : 36 grams
Megapixels : 0.4
Non-isolated I/O Ports : 1 bi-directional, 1 input
Operating Humidity : 20 to 80% (no condensation)

Storage Humidity : 30 to 95% (no condensation)
Storage Temperature : -30° to 60°C

COMPLIANCE & CERTIFICATIONS

Compliance CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099.
Machine Vision Standard USB3 Vision v1.0
Warranty 3 years

Lens Mount : CS-mount
ADC : 8-bit, 10-bit, 12-bit
Required Accessories : Lens, Cable, Host Adapter (USB 3.1 Gen 1), Tripod Mount Adapter (ACC-01-0003)
Acquisition Modes : Continuous Single Frame Multi Frame
Exposure Range : 4 µs to 30 seconds
Flash Memory : 6 MB non-volatile memory
Gain Range : 0 db to 47 dB
Image Buffer : 240MB
Image Processing : Gamma, lookup table, and sharpness
Partial Image Modes : Pixel binning, decimation, ROI

PERFORMANCE

Absolute Sensitivity Threshold (y) : 6.81
Dynamic Range dB : 74.43
Power Consumption : 3 W
Quantum Efficiency : 61.82 (530nm)
Saturation Capacity (e-) : 22187
Temporal Dark Noise (e-) : 3.71

Operating Temperature : 0° to 50°C
Opto-isolated I/O Ports : 1 input, 1 output
Part Number : BFS-U3-04S2M-CS
Pixel Size : 6.9
Power Requirements : 8-24 V via GPIO or 5 V via USB3
Readout Method : Global shutter
Resolution : 720 × 540
Sensor Format : 1/2.9
Sensor Name : Sony IMX287
Sensor Type : CMOS

RECOMMENDED SYSTEM CONFIGURATION

CPU : 3.1 GHz or equivalent CPU
Hard Drive : 200 MB hard drive space
Operating System : Windows or Linux (32–bit or 64–bit)
Port : USB 3 Port
RAM : 2 GB RAM or more
Required Accessories : Lens, Cable, Host Adapter (USB 3.1 Gen 1), Tripod Mount Adapter (ACC-01-0003)

BFS-U3-04S2M-CS: 0,4 MP, 522 FPS, Sony IMX287, Mono

Blackfly S USB3

The Blackfly® S leverages the industry’s most advanced sensors in an ice-cube form factor. It is packed with powerful features enabling you to easily produce the exact images you need and accelerate your application development. This includes both automatic and precise manual control over image capture and on-camera pre-processing. The Blackfly S is available in GigE, USB3, cased, and board-level versions.
