HATTELAND® Series X G1 - 8.0 Inch
Featured Information
HATTELAND® Series X G1 - 8.0 Inch
SPESIFICATIONS
- TFT Technology : LED Backlight Technology, TTL Interface, a-si TFT Active Matrix, Widescreen
- Viewable Size and Active Area : 8.0 inch - 173.40 [6.83''] (H) x 104.40 [4.11''] (V) mm [inch]
- Native Resolution and Pixel Pitch : 800 x 480 (WVGA) - 0.2168 (H) x 0.2168 (V) mm
- Aspect Ratio and Response Time : 5:3 - 5/11ms (typ) (Tr/Tf)
- Light Intensity and Contrast Ratio : 600 cd/m² (typ) - 600:1 (typ)
- View Angle and Max Colors : 70 deg. (up/down) / 60 deg. (left/right) - 16.7 million
- Optimal Resolution and Hz : 800 x 480 @ 60 Hz
- Detectable Resolutions : 800x480
- Composite Video Input(s) : None
- Product Features : Projected Capacitive Technology (PCTouch) MULTITOUCH, Dimmable 0-100%, Buzzer
- Power Specifications and Consumption : 2 x 24VDC, Galvanic Isolated, Automatic Switch <> sources 20W (typ) - 75W (max)
- User Controls and Activity : Glass Display Control™ (GDC) IP66 with: Power On/Off, Brightness Control (-/+), Light Sensor (not visible), Programmable Alarm LED, Buzzer (not visible)
- Connectors : • DVI IN: 1 x DVI-I 29P (female) or VGA IN via Adapter • Touchscreen: 1 x USB Type B (female). Use USB2.0 (<5m) port. • DC Power IN: 2 x 2-pin Terminal Block 5.08
- Product Dimensions and Weight : W:236.00 [9.29''] x H:166.00 [6.54''] x D:51.00 [2.01''] mm [inch] 4 x M4 VESA mounting 75x75mm, Max 8mm deep Built-in Console mounting 4 x M5x15mm screws 1.7kg / 3.7lbs
- Product Carton Size and Weight: L:320.00 [12.60''] x W:180.00 [7.09''] x H:320.00 [12.60''] mm [inch] 2.5kg / 5.5lbs
- Operating Temperature : -15.0°C / 5.0°F to 55.0°C / 131.0°F, Humidity up to 95%
- Storage Temperature : -20.0°C / -4.0°F to 60.0°C / 140.0°F, Humidity up to 95%
- IP Rating : Protection: IP66 front - IP20 rear (EN60529)
- Compass Safe Distance : Standard: 45.00 [17.72''] - Steering: 30.00 [11.81''] cm [inch]
HATTELAND® Series X G1 - 8.0 Inch
The Series X display range is a flexible monitor solution designed and type approved for the professional maritime segment, where reliability and long life time are key prerequisites for the industry. The product range combines stunning design and technology with innovative features and options, making it all that the integrator needs for top class type-approved marine systems. The entry level STD models provide a wide choice of display size and format for shipboard applications where simple data input (DVI & VGA) is required. Be it for ship navigation or automation, this range with all it's possible options provides a robust and cost effective platform from which to display and manage data. This model is delivered with a factory mounted Projected Capacitive Touch Screen (Multitouch, USB interface) as standard and feature LED Backlight Technology.
