HIGH SPEED, HIGH RESPONSE MULTILINE-CMOS
HIGH SPEED, HIGH RESPONSE MULTILINE-CMOS
Model :ELiiXA+ Mono 16K/8K - CXP - Dörtlü Hat (BA0)

Featured Information

Part number :
EV71YC4MCP1605-BA0
Resolution :
16384x4 CMOS
Spectrum :
Mono
Product thumb
ELiiXA+ Mono 16K/8K - CXP - Dörtlü Hat (BA0)
HIGH SPEED, HIGH RESPONSE MULTILINE-CMOS

Features :

  • Part number :   EV71YC4MCP1605-BA0
  • Resolution :  16384x4 CMOS
  • Spectrum :  Mono
  • Interface :  CoaXPress
  • Pixel Size :  5 µm
  • Max Line Rate :  100 kHz
  • Total Pixels :  ~ 16 k
  • Bit Depth :  8 bit, 10 bit, 12 bit
  • Operating Temperature :   0—70 °C
  • Dynamic Range :  70 dB

  • Supported Lens Options :  M-95 native
  • Dimensions (W x H x L) :  100 x 156 x 36 mm
  • Mass :   700 g

Product thumb
ELiiXA+ Mono 16K/8K - CXP - Dörtlü Hat (BA0)
HIGH SPEED, HIGH RESPONSE MULTILINE-CMOS

The ELiiXA+ family features Teledyne e2v’s recently developed multi-line CMOS technology, providing high line rates and combining high response with extremely low noise levels. This delivers high signal to noise ratio even when short integration times are required or when illumination is limited. Pixels are arranged in two active lines and dual line filter configuration allows the cameras to be operated in several modes.
