Blackfly USB3
Blackfly USB3
Model :BFLY-U3-13S2M-CS
: (Discontinued)
Featured Information
Part Number :
BFLY-U3-13S2M-CS
Resolution :
1288 × 964
Frame Rate :
30
BFLY-U3-13S2M-CS
Blackfly USB3
SPECIFICATIONS
- Part Number : BFLY-U3-13S2M-CS
- Resolution : 1288 × 964
- Frame Rate : 30
- Megapixels : 1.3
- Chroma : Mono
- Sensor Name : Sony ICX445
- Sensor Type : CCD
- Sensor Format : 1/3
- Readout Method : Global shutter
- Pixel Size : 3.75
FEATURES
- Exposure Range : 0.044 ms to 32 seconds
- Flash Memory : 1 MB non-volatile memory
- Frame Rate : : 30
- Gain Range -11 dB to 24 dB
- Image Buffer : 16 MB
- Image Processing : Gamma, lookup table, hue, saturation, and sharpness
- Partial Image Modes : Pixel binning, decimation, ROI
- Trigger Modes : Standard, bulb, low smear, overlapped, multi-shot
- User Sets : 2 user configuration sets for custom camera settings
PHYSICAL
- ADC : 12-bit
- Auxiliary Output : 3.3 V, 150 mA maximum
- Chroma : Mono
- Dimensions [W x H x L] : 29 mm × 29 mm ×30 mm
- Interface : USB 3.1 Gen 1
- Lens Mount : CS-mount (5 mm C-mount adapter not included)
- Mass : 36 grams
- Megapixels : 1.3
- Operating Humidity : 20 to 80% (no condensation)
- Operating Temperature : 0° to 45°C
- Storage Temperature : -30° to 60°C
COMPLIANCE & CERTIFICATIONS
- Compliance : CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099.
- Machine Vision Standard : USB3 Vision v1.0
- Warranty : 3 years
- Lens Mount : CS-mount (5 mm C-mount adapter not included)
- ADC : 12-bit
- Required Accessories : Lens, Cable, Host Adapter (USB 3.1 Gen 1), Tripod Mount Adapter (ACC-01-0003)
PERFORMANCE
- Absolute Sensitivity Threshold (y) : : 16.01
- Dynamic Range dB : : 59.84
- Quantum Efficiency 60.38 (530nm)
- Saturation Capacity (e-) : : 9487
- Temporal Dark Noise (e-) : 9.17
- Opto-isolated I/O Ports : 1 input, 1 output
- Part Number : BFLY-U3-13S2M-CS
- Pixel Size : 3.75
- Power Requirements : : 5-24 V via GPIO or 5 V via USB3
- Readout Method Global shutter
- Resolution : 1288 × 964
- Sensor Format : 1/3
- Sensor Name : Sony ICX445
- Sensor Type : CCD
- Storage Humidity : 20 to 95% (no condensation)
RECOMMENDED SYSTEM CONFIGURATION
- CPU : 3.1 GHz or equivalent CPU
- Hard Drive : 200 MB hard drive space
- Operating System : Windows or Linux (32-bit or 64-bit)
- Port : USB 3 Port
- Required Accessories : Lens, Cable, Host Adapter (USB 3.1 Gen 1), Tripod Mount Adapter (ACC-01-0003)
BFLY-U3-13S2M-CS
Blackfly USB3
The Blackfly® camera line combines Sony CCD, Aptina, e2v, and Sharp sensors with a host of unique features. For FLIR area scan cameras with the latest sensors and most advanced feature sets, please refer to our Blackfly S and Oryx camera families.
