LMX-1802G-SFP
18-Port Industrial Gigabit Light Layer 3 Managed Ethernet Switch, w/16*10/100/10...
LMX-1802G-SFP
18-Port Industrial Gigabit Light Layer 3 Managed Ethernet Switch, w/16*10/100/1000Tx Ports + 2*100/1000 SFP Ports
Featured Information
Supports 16*10/100/1000Tx Gigabit Ports
2*100/1000 SFP ports
Network Broadcast Storm Protection
LMX-1802G-SFP
18-Port Industrial Gigabit Light Layer 3 Managed Ethernet Switch, w/16*10/100/1000Tx Ports + 2*100/1000 SFP Ports
FEATURES
- Supports 16*10/100/1000Tx Gigabit Ports
- 2*100/1000 SFP ports
- Network Broadcast Storm Protection
- Network Redundancy Support : RSTP/MSTP, and G.8032 ERPS (Recovery time <50ms)
- Configuration : Web Console, Serial, CLI Command
- Supports IGMP v1/v2
- Supports QoS (IEEE 802.1p) and CoS/ToS
- Supports IEEE 802.1Q VLAN, SNMP v1/v2c/v3
- Redundant Power Input Design 12~48VDC + Built-in Relay Output for Port Break Alarm
- System Warning Setting for Automatic Warning through E-mail
- Shock : IEC60068-2-27
- Protocols : IPv4/IPv6, SNMP v1/v2c/v3, LLDP, LLDP-MED, HTTP, HTTPS, SSHv2 telnet, DHCP client, DHCPv6 client, DHCP server, Port Mirror, DNS client/proxy, IP based Access Filter, ICMPv6, syslog, Time Zone / Daylight Saving, NTP client, RMON, sFlow, Loop detection, Console Port, Power Lost Warning, Relay Trigger
- Switching Architecture : Back-Plane (Switching Fabric): 36.0Gbps
- Flow Control : EEE 802.3x for full duplex mode, back pressure for half duplex mode
- Transfer Rate : 14,880pps for 10Base-T Ethernet 148,800pps for 100Base-T Fast Ethernet 1,488,000pps for Gigabit Ethernet
- Packet Buffer : 4Mbits
- Jumbo Frame : 9.6Kbytes
- MAC Table Size : 8K
- VLAN Groups : 4095
- IGMP Group : 1024
- Dimensions : 67 x 142 x 99 mm (W x H x D)
- Weight : Unit: 2.65 Ibs Shipping: 3.09 Ibs
- Mounting : DIN-Rail mounting; Wall mounting
- Input Voltage : 12~48VDC Redundant Input
- Power Connection : 1 removable 4-contact and 2-contact terminal block
- System Power Consumption : 16.1 Watts
- Operating Temperature : -10°C to 70°C
- Storage Temperature : -40°C ~ 85°C
- Ambient Relative Humidity : 5 to 95%, (non-condensing)
- EMI : FCC Part 15 Subpart B Class A CE EN55032/EN61000-6-4 Class A
- Network Redundancy : STP/RSTP/MSTP, port trunk with LACP, ERPS v1/v2 (<50ms)
- Configuration : Http, Https, Telnet, SSH, CLI, TFTP, SNMP v3
- System / Diagnostics : Dual Image Protection, PING, PING6
- DIN-Rail and Wall Mount Support
- Operating Temperature Range - STD : -10°C to 70°C
- 5-Year Warranty
- Ethernet Port : 16*10/100BaseTx Auto negotiation speed, Full/Half duplex mode, and auto MDI/MDI-X connection
- Fiber Port : 2*100/1000 SFP Slots
- Wavelength : Depends on SFP modules
- RS232 Serial Console : 1*RS232 in RJ45 connector with console cable, 115.2Kbps, 8, N, 1
- Configuration backup : 1*USB 2.0
- Overload Current Protection : Present
- Reverse Polarity Protection : Present (the unit will not be on, if power reverse)
- Network Cable : 10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable; EIA/TIA-568 100-ohm (100m) 100Base-TX: 2-pair UTP/STP Cat. 5 cable; EIA/TIA-568 100-ohm (100m) 1000Base-TX: 4-pair UTP/STP Cat.5/5E cable; EIA/TIA-568 100-ohm (100m)
- Vibration : IEC60068-2-6
- Housing : Metal, IP30 rated
- EMS : CE EN55035/EN61000-6-2 Class A EN61000-4-2,3,4,5,6,8
- Free Fall : IEC60068-2-32
- Green : RoHS Compliant
- Certifications : FCC, CE, UL 61010-1, 61010-2-201, NEMA TS2
- Warranty : 5 Years
- Processing Type : Store and Forward
- L2 Switching : Port/MAC/Protocol/IP Subnet-based VLAN, GARP/GVRP, Loop Guard, Link Aggregation static/LACP, BPDU guard, Error disable recovery, IGMP snooping v2/v3, MLD snooping v1/v2, IGMP filtering, IPMC throttling / filtering leave proxy, DHCP snooping, G.8032 v1/v2
- L3 Switching : DHCP option82, static routes
- QoS : 802.1p Queueing, Input priority mapping, Storm control for Unicast/Multicast/Broadcast, Port/Queue/ACL policer, Port egress shaper, Queue egress shaper, DiffServ (DSCP), Tag remarking, Scheduler mode
- Power Saving : ActiPHY, PerfectReach, IEEE 802.3az EEE power management
- LMX-1802G-SFP
- Quick Installation Guide
- Wall mounting bracket set with screws
- 1 - RJ45 to DB9 Serial Console Cables
- 1 - DC Cable - 18 AWG & DC Jack 5.5 X 2.1 mm
- RJ45 dust cover set
LMX-1802G-SFP
18-Port Industrial Gigabit Light Layer 3 Managed Ethernet Switch, w/16*10/100/1000Tx Ports + 2*100/1000 SFP Ports
Antaira’s LMX-1802G-SFP is an 18-port industrial Gigabit Light Layer 3 Managed Ethernet switch that is embedded with 16*10/100/1000Tx Gigabit ports and 2*100/1000 SFP ports. This model is a fully manageable industrial Ethernet switch pre-loaded with standard Light Layer 3 network management software. The LMX-1802G-SFP has a compact form factor design with an IP30 rating, DIN-rail mounting, and standard operating temperature support from -10°C to 70°C. It also provides high EFT and ESD protection for any industrial networking application within factory automation, ITS, power/utility, water wastewater, Security, or any other outdoor or harsh environment.
