Model :ORX-10G-310S9C: 31 MP, 26 FPS, Sony IMX342, Color

Featured Information

Part Number :
ORX-10G-310S9C
Resolution :
6464 x 4852
Frame Rate :
26
Product thumb
ORX-10G-310S9C: 31 MP, 26 FPS, Sony IMX342, Color
Oryx 10GigE

SPECIFICATIONS

  • Part Number :  ORX-10G-310S9C
  • Resolution :  6464 x 4852
  • Frame Rate :  26
  • Megapixels :  31
  • Chroma :  Color
  • Sensor Name :  Sony IMX342
  • Sensor Type :  CMOS
  • Sensor Format :  APS-C
  • Readout Method :  Global shutter
  • Pixel Size :  3.45

FEATURES

  • Acquisition Modes :  Continuous Single Frame Multi Frame
  • Exposure Range :  39.0 µs to 30.0 S
  • Flash Memory :  4 MB non-volatile memory
  • Frame Rate :  26
  • Gain Range :  0 dB to 47 dB
  • Image Buffer :  240 MB
  • Image Processing :  Gamma, lookup table, pixel correction, target grey value, and sharpness
  • Partial Image Modes :  Pixel binning, decimation, ROI
  • User Sets :  2 user configuration sets for custom camera settings

PHYSICAL

  • ADC :  8-bit, 10-bit, 12-bit
  • Auxiliary Output :  3.3 V, 120 mA maximum
  • Chroma :  Color
  • Dimensions [W x H x L] :  60 mm x 60 mm x 115 mm
  • Interface :  10 GigE
  • Lens Mount :  F-mount sold separately
  • Mass :  508 grams
  • Megapixels :  31
  • Non-isolated I/O Ports :  2 bi-directional
  • Operating Humidity :  20 to 80% (no condensation)

  • Sensor Type :  CMOS
  • Serial Port :  1 (over non-isolated I/O)
  • Storage Humidity :  30 to 95% (no condensation)
  • Storage Temperature :  -30° to 60°C

COMPLIANCE & CERTIFICATIONS

  • Compliance :  CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099
  • Machine Vision Standard :  GigE Vision v1.2
  • Warranty :  3 years

  • Lens Mount :  F-mount sold separately
  • ADC :  8-bit, 10-bit, 12-bit
  • Required Accessories :  Lens, Cable, Host Adapter (10GigE), Power Supply (ACC-01-9013 ), Lens Adapter F-Mount (ACC-01-5014)

PERFORMANCE

  • Absolute Sensitivity Threshold (y) :  8.00
  • Dynamic Range dB :  67.17
  • Quantum Efficiency Blue :  48 (460 nm)
  • Quantum Efficiency Green :  60 (530 nm)
  • Quantum Efficiency Red :  47 (625 nm)
  • Saturation Capacity (e-) :  10908
  • Temporal Dark Noise (e-) :  4.28

  • Operating Temperature :  0° to 50°C
  • Opto-isolated I/O Ports :  1 input, 1 output
  • Part Number :  ORX-10G-310S9C
  • Pixel Size :  3.45
  • Power Consumption [Maximum] :  Maximum: 13.9 W, Nominal: 13.6 W, GPIO power only
  • Power Requirements :  12-24 V, via GPIO interface
  • Readout Method :  Global shutter
  • Resolution :  6464 x 4852
  • Sensor Format :  APS-C
  • Sensor Name :  Sony IMX342

RECOMMENDED SYSTEM CONFIGURATION

  • CPU :  3.1 GHz or equivalent CPU
  • Hard Drive :  200 MB hard drive space
  • Operating System :  Windows or Linux (32–bit or 64–bit)
  • Port :  Gigabit Ethernet Port
  • Power Sourcing Equipment :  Camera Power Supply (12v 1.5A, 12–pin Hirose)
  • RAM :  2 GB RAM or more
  • Required Accessories :  Lens, Cable, Host Adapter (10GigE), Power Supply (ACC-01-9013 ), Lens Adapter F-Mount (ACC-01-5014)

Product thumb
ORX-10G-310S9C: 31 MP, 26 FPS, Sony IMX342, Color
Oryx 10GigE

The award-winning Oryx 10GigE camera family allows systems designers to take advantage of the latest sensors by supporting transfer speeds of up to 10 Gbit/s enabling capture of 4K resolution, 12-bit images at over 60 FPS. Oryx features include IEEE1588 clock synchronization and full compatibility with several popular third-party software supporting GigE Vision. Oryx’s 10GBASE-T interface is a proven and widely deployed standard that provides reliable image transfer at cable lengths over 50 meters on inexpensive CAT6A, and up to 30 meters on CAT5e.
