FLIR M618CS

Pan/Tilt Marine Thermal Camera

FLIR M618CS

Pan/Tilt Marine Thermal Camera

Featured Information

Thermal Detector Type :

640 × 480 VOx Microbolometer

Thermal Field of View :

18° × 14° (NTSC)

Thermal Focal Length :

35 mm

FLIR M618CS

Pan/Tilt Marine Thermal Camera

THERMAL CAMERA SPECIFICATIONS

Thermal Detector Type : 640 × 480 VOx Microbolometer
Thermal Field of View : 18° × 14° (NTSC)
Thermal Focal Length : 35 mm
Thermal E-Zoom : 2x & 4x
Image Processing : FLIR Proprietary Digital Detail Enhancement

SYSTEM SPECIFICATIONS

Size : 7 inch dia. x 11.4 inch ht.
Weight : 11.5 lb (5.2 kg)
Stabilization : 2-Axis Gyro-Stabilization
Pan/Tilt Coverage : 360° Continuous Pan +/- 90° Tilt
Video Output : NTSC or PAL
Connector Types : BNC with BNC-to-RCA adapter included for video out
Power Requrements : 12 VDC to 24 VDC
Power Consumption : 25 W nominal; 50 W max

VISIBLE CAMERA SPECIFICATIONS

Visible Field of View : 58° (h) x 43° (v) w/ 10x optical zoom slaved to thermal camera
Lines of Resolution : 530
Minimum Illumination : 1.4 Lux

ENVIRONMENTAL

Operating Temperature Range : -25°C to +55°C
Storage Temperature Range : -40°C to +85°C
Automatic Window Defrost : Standard
Sand / Dust : MIL-STD-810E
Water Ingress : IPX6
Shock : 15g vertical, 9g horizontal
Vibration : IEC 60945; MIL-STD-810E
Lightning Protection : IEC60945
Salt Mist : IEC60945
Wind : 100 knot (115.2 mph)

FLIR M618CS

Pan/Tilt Marine Thermal Camera

The M-Series pan/tilt re-defines maritime multi-sensor system design, drawing on FLIR’s 25 years of experience in building combat-proven airborne and maritime thermal imagers for militarys, coast guards, and governmental agencies around the world. With up to 640 x 480 thermal imaging, M-Series cameras let you see more — and see farther — than ever before. Even in the dead of night.
