Model :Falcon4-CLHS M4400

Featured Information

Part number :
FA-HM01-M4405
Resolution :
4480 x 2496
Spectrum :
Mono
Product thumb
Falcon4-CLHS M4400
True High Performance

Features :

  • Part number :  FA-HM01-M4405
  • Resolution :  4480 x 2496
  • Spectrum :  Mono
  • Interface :  Camera Link Hs
  • Pixel Size :  6 µm
  • Max Frame Rate :  330 fps
  • Total Pixels :  ~ 11,2 MP
  • Interface Speed :  41.2 Gbps
  • Bit Depth :  8 bit, 10 bit
  • Operating Temperature :  -20—65 °C

  • Supported Lens Options :  M42 x 1 mm
  • Shutter Type :   Global Shutter
  • Power Requirement :  10 V to 30 V DC
  • Synchronisation :  Software trigger, free-run, & hardware trigger
  • Exposure Control :  INTERNAL: Programmable via the camera API, EXTERNAL: Based on Trigger Width
  • General Purpose I/O :  2 input / 3 Output, Opto-coupled
  • Dimensions (W x H x L) :  59 x 59 x 70 mm
  • Mass :  320 gr

For true high-performance imaging, turn to the Falcon™4-CLHS camera series. Using Teledyne Imaging’s advanced CMOS architectures, the Falcon4-CLHS cameras offer unique, unprecedented capabilities for large area, high-resolution, high-speed imaging. Models range from 2.8 megapixels to 67 megapixels, with frame rates up to 1200 fps.
