CMOS LINE SCAN BUILT FOR MAXIMUM THROUGHPUT
CMOS LINE SCAN BUILT FOR MAXIMUM THROUGHPUT
Model :Piranha4 2k, 100/200 kHz

Featured Information

Part number:
P4-CM-02K10D
Resolution :
2048 x 2
Spectrum :
Mono
Product thumb
Piranha4 2k, 100/200 kHz
CMOS LINE SCAN BUILT FOR MAXIMUM THROUGHPUT

Features :

  • Part number:   P4-CM-02K10D
  • Resolution :  2048 x 2
  • Spectrum :  Mono
  • Interface :  Camera Link
  • Pixel Size :  10.56 µm
  • Max Line Rate :  200 kHz
  • Total Pixels :  ~ 2 k
  • Bit Depth :  8 bit, 10 bit, 12 bit
  • Operating Temperature :   0—65°C
  • Responsivity :   65 DN/nJ/cm2 @ 1x gain, 8-bit

  • Dynamic Range :   65 dB
  • Dimensions (W x H x L) :   62 x 62 x 48 mm

Product thumb
Piranha4 2k, 100/200 kHz
CMOS LINE SCAN BUILT FOR MAXIMUM THROUGHPUT

The Piranha4 cameras offer advanced features such as sub-pixel spatial correction, areas of interest (up to 4 at a time) to reduce data processing and simplify cabling, as well as dual-line area mode to double line rate, HDR mode, shading and lens correction. The Piranha4 is built for the real world with features to ease system integration. The advanced GenICam compliant user interface makes it easy to set up and control camera parameters such as exposure control, FFC, white balance, gain, test patterns, diagnostics and more.
