Xtium-CLHS PX8
Feature-rich CLHS acquisition and processing
Xtium-CLHS PX8
Feature-rich CLHS acquisition and processing
Featured Information
Part Number :
OR-Y8S0-XPX70
Board Type :
PCIe
Host Bus :
PCIe Gen2 x8
Xtium-CLHS PX8
Feature-rich CLHS acquisition and processing
Specifications
- Part Number : OR-Y8S0-XPX70
- Board Type : PCIe
- Host Bus : PCIe Gen2 x8
- Board Interface : Camera Link HS
- Connectors : Data Input: 1 x CX4 thumbscrew Data Forward: 1 x CX4 thumbscrew Controls: 1xDH60-27P (main bracket) for external Trigger input, strobe output, Quadrature Encoder input and General I/Os 1x26-pin shrouded header Onboard 16-pin shrouded connector: For multi-board Board Sync
- Camera Format : CLHS Rev 1.0 1, 4, and 7 lane configurations
- Pixel Clock : N/A
- Transmission Rate : 3.25Gb/s and 5.0Gb/s
- Bits per Pixel : Mono8, Mono10, Mono12, and Mono16
- GPIO : 4-opto in (selectable threshold)(2-shared with ext. trig in); 8-output TTL(1-shared with strobe out)
- Camera Control : External Trigger input, Strobe out, Quadrature Encoder, Mulit-board Sync.
- Frame Buffer : 1024 MB
- Features : Data Forwarding, Board Sync Lookup table, user programmable 3x3 filter, Active Optical Cable (AOC) fiber cables ready
- Software : Sapera LT SDK, Sapera Vision Software
- OS Support : Windows 7 (32-bit)*, Windows 7 (64-bit)*, Windows 8 (32-bit), Windows 8 (64-bit), Windows 10 (32-bit), Windows 10 (64-bit), Linux (64-bit), WoW64
Xtium-CLHS PX8
Feature-rich CLHS acquisition and processing
Building on the field proven capability of Teledyne DALSA’s Xcelera frame grabber series, the Xtium™-CLHS PX8 is based on AIA’s CameraLink HS standard and uses PCI Express™ Gen 2.0 expansion bus to deliver high speed image acquisition and image transfer to the host memory. Xtium-CLHS uses industry standard CX4 cable to delivery up to 2.1 GB/s of image acquisition over a single cable to go beyond 15m and host transfer speeds of up to 3.2GB/sec - all in a compact, half-length, single slot solution.
