Model :BFS-GE-122S6M-BD2: 12.3 MP, 10 FPS, Sony IMX304, Mono
Featured Information
Part Number :
BFS-GE-122S6M-BD2
Resolution :
4096 × 3000
Frame Rate :
10
BFS-GE-122S6M-BD2: 12.3 MP, 10 FPS, Sony IMX304, Mono
Blackfly S Board Level
SPECIFICATIONS
- Part Number : BFS-GE-122S6M-BD2
- Resolution : 4096 × 3000
- Frame Rate : 10
- Megapixels : 12.3
- Chroma : Mono
- Sensor Name : Sony IMX304
- Sensor Type : CMOS
- Sensor Format : 1.1"
- Readout Method : Global shutter
- Pixel Size : 3.45
FEATURES
- Acquisition Modes : Continuous Single Frame Multi Frame
- Exposure Range : 36 µs to 30 seconds
- Flash Memory : 6 MB non-volatile memory
- Frame Rate : 10
- Gain Range : 0 dB to 47dB
- Image Buffer : 240 MB
- Image Processing : Gamma, lookup table, and sharpness
- Partial Image Modes : Pixel binning, decimation, ROI
- User Sets : 2 user configuration sets for custom camera settings
PHYSICAL
- ADC : 12-bit
- Auxiliary Output : 3.3 V, 120 mA maximum
- Chroma : Mono
- Dimensions [W x H x L] : 29 mm × 29 mm × 10 mm
- Interface : GigE
- Lens Mount : Lens mount sold separately
- Mass : 10 grams
- Megapixels : 12.3
- Non-isolated I/O Ports : 3 bi-directional
- Operating Humidity : 20 to 80% (no condensation)
- Storage Humidity : 30 to 95% (no condensation)
- Storage Temperature : -30° to 60°C
COMPLIANCE & CERTIFICATIONS
- Compliance : CE, FCC, RoHS. The ECCN for this product is: EAR099
- Machine Vision Standard : GigE Vision v1.2
- Warranty : 3 years
- Lens Mount : Lens mount sold separately
- ADC : 12-bit
- Required Accessories : Lens mount and lens, cable, host adapter (GigE), TF38 to FPC RJ45 PoE panel mount adapter (ACC-02-7002), heatsink (recommended)
PERFORMANCE
- Absolute Sensitivity Threshold (y) 4.34
- Dynamic Range dB 71.61
- Quantum Efficiency 65.14
- Saturation Capacity (e-) 10764
- Temporal Dark Noise (e-) 2.33
- Operating Temperature : 0° to 50°C
- Part Number : BFS-GE-122S6M-BD2
- Pixel Size : 3.45
- Power Consumption [Maximum] : 3 W (2.8 W nominal)
- Power Requirements : 5 V via FPC connector
- Readout Method : Global shutter
- Resolution : 4096 × 3000
- Sensor Format : 1.1"
- Sensor Name : Sony IMX304
- Sensor Type : CMOS
RECOMMENDED SYSTEM CONFIGURATION
- CPU : 3.1 GHz or equivalent CPU
- Hard Drive : 200 MB hard drive space
- Operating System : Windows or Linux (32–bit or 64–bit)
- Port : Gigabit Ethernet Port
- RAM : 2 GB RAM or more
- Required Accessories : Lens mount and lens, cable, host adapter (GigE), TF38 to FPC RJ45 PoE panel mount adapter (ACC-02-7002), heatsink (recommended)
BFS-GE-122S6M-BD2: 12.3 MP, 10 FPS, Sony IMX304, Mono
Blackfly S Board Level
The FLIR Blackfly S Board Level variants are high performance, machine vision, area scan cameras designed for embedding into tight spaces. Unlike many board level cameras, it boasts a rich feature set applied to the latest CMOS sensors; the same feature set as the cased version. It is ready for integration with proven compatibility with popular SBCs and SOMs. The Blackfly S board level models enable OEMs to develop smaller, lighter, and lower cost solutions with embedded system connectivity and rich features.
