Xtium-CL MX4
Proven Capability. High Speeds.
Xtium-CL MX4
Proven Capability. High Speeds.
Featured Information
Part Number :
OR-Y4C0-XMX00
Board Type :
PCIe
Host Bus :
PCIe Gen2 x4
Xtium-CL MX4
Proven Capability. High Speeds.
Specifications
- Part Number : OR-Y4C0-XMX00
- Board Type : PCIe
- Host Bus : PCIe Gen2 x4
- Board Interface : Camera Link
- Connectors : Data: 2xSDR (mini CameraLink), Control: 1x DH60-27pin on main bracket 1 x 26-pin for internal connections 1x16 shrouded connector
- Camera Format : 2 x CameraLink Base or 1 x CameraLink Medium, Full or 80-bit (Deca)
- Pixel Clock : 20 ila 85 MHz
- Bits per Pixel : 8, 10, 12, 14 and 16-bit/pixel
- Number of Camera Taps : 1 Tap – 8/10/12/14/16-bit mono/bayer; 8/10/12-bit RGB 2 Taps – 8/10/12-bit mono/bayer; 8-bit RGB 3 Taps – 8/10/12-bit mono/bayer 4 Taps – 8/10/12-bit mono/bayer 64-bits: 8 Taps – 8-bit mono/bayer Full packed 8-bit RGB/BGR/RGBY 80-bit: 8-Taps – 10-bit/pixel mono/bayer 10 Taps – 8-bit/pixel mono/bayer Packed 8/12-bit RGB/BGR or Packed 8-bit Bi-Color
- GPIO : Inputs: 4 independent optically isolated (2 shared with ext. trig); Output: 8-TTL (2 shared with strobe)
- Camera Control : External Trigger input, Strobe output, Quadrature Encoder Input
- Frame Buffer : 512 MB
- Features : PoCL ILUTs, Dead Pixel(3x2), User programmable 3x3 filter, Metadata, Strobe cycling/line-by-line, Bayer and Bi-color conversion
- Software : Sapera LT SDK, Sapera Vision Software
- OS Support : Windows 7 (32-bit)*, Windows 7 (64-bit)*, Windows 8 (32-bit), Windows 8 (64-bit), Windows 10 (32-bit), Windows 10 (64-bit), Linux (64-bit), WoW64
Xtium-CL MX4
Proven Capability. High Speeds.
Building on the field proven capability of Teledyne DALSA’s Xcelera frame grabber series, the Xtium™-CL MX4 is based on industry standard PCI Express™ Gen 2.0 expansion bus to deliver high speed access to host memory. The new Xtium series offers higher bandwidth to sustain Camera Link® 80-Bit modes over longer cable distances and supports a wide variety of area and line scan color/monochrome cameras, all in a compact, half-length, single slot solution
