FLIR M364

Marine Thermal Cameras with Active Gyro-Stabilization

FLIR M364

Marine Thermal Cameras with Active Gyro-Stabilization

Featured Information

Automatic Window Defrost :

Standard at Power-Up

EMI :

IEC60945

Lightning Protection :

Near Strike at 2kV

FLIR M364

Marine Thermal Cameras with Active Gyro-Stabilization

ENVIRONMENTAL

Automatic Window Defrost : Standard at Power-Up
EMI : IEC60945
Lightning Protection : Near Strike at 2kV
Operating Temperature Range : -13°F to +131°F (-25°C to +55°C)
Salt Mist : IEC60945
Sand & Dust Ingress : Mil-Std-810E or IP6X
Shock : 15g vertical, 9g horizontal
Storage Temperature Range : -22°F to +158°F (-30°C to +70°C)
Vibration : IEC60945
Water Ingress : IPX6 (heavy seas, power jets of water)

OTHER

Pan and Tilt Adjustment Range : 360° Continuous Pan, +110°/- 90° Tilt

RANGE PERFORMANCE

Detect a 30-foot Vessel : 1.7nm (3150m)
Detect Human Sized Target : 0.5nm (925m)
NATO Target 2.3m x 2.3m at 50 Pct. : 0.9nm (1690m)

Pan-Tilt Adjustment Range : 360° Continuous Pan, ± 90° Tilt
Power Consumption : 41 W (typical) 56 W (max)

Wind : 100 knots (115.2 MPH)

PHYSICAL

Power Requirements : 12 to 24vDC (24vDC recommended)
Size : Camera: 8.7” (222mm) x 12.9” (328mm) / Camera with Top-Down Riser: 10.0” (254mm) x 14.4” (366mm)
Weight : Camera: 13.9lbs (6.3kg) / Camera with Top-Down Riser: 14.9lbs (6.8kg)

SYSTEM SPECIFICATIONS

Analog Video Connector Types : BNC
Analog Video Output : NTSC/PAL User Settable
ClearCruise IR Analytics : Yes, with Raymarine Axiom
Current : Peak 10.0 A
Firefighter Mode : No
Gyro Stabilized : Yes
HD-SDI Lossless Video Output : Yes
Network Video Output : Two, Independent H.264/MJPEG Network Video Streams
ONVIF Conformance : Profile S
Operating Voltage Range : -10% to +30% of Nominal Supply Range

THERMAL CAMERA

Focus : Fixed 12 ft (3m) to infinity
Image Processing : FLIR Proprietary Digital Detail Enhancement
Thermal Detector Type : 640x512 VOx Microbolometer
Thermal E-Zoom : 8x Continuous
Thermal Field of View : 24 ° x 18 °
Thermal Focal Length : 18 mm
Video Refresh Rate : 30 Hz or <9 Hz

FLIR M364

Marine Thermal Cameras with Active Gyro-Stabilization

Pairing a rugged, all-weather design with one of the most advanced FLIR thermal imaging cores, the M332 and M364 deliver awareness-enhancing thermal vision for law enforcement, commercial, and recreational applications. Advanced gyro-stabilization and high-performance thermal imaging detect obstacles and targets in complete darkness and heavy seas, allowing safe navigation in the most challenging conditions.
