FLIR MD324
Compact Fixed View Marine Thermal Camera
FLIR MD324
Compact Fixed View Marine Thermal Camera
Featured Information
Field of View :
24° x 18° (NTSC)
Resolution :
320 x 240
Size :
6
FLIR MD324
Compact Fixed View Marine Thermal Camera
GENERAL
- Field of View : 24° x 18° (NTSC)
- Resolution : 320 x 240
- Size : 6
- Standard Package : Camera Head with ~5
- Detector Type : VOx Microbolometer
- Focal Length : 13 mm
- Weight : ~ 3 lbs
CONNECTIONS & COMMUNICATIONS
- Construction Type : F-type BNC with BNC-to-RCA adapter included for video out
- Video Output : NTSC or PAL, 30 Hz or <9Hz
ENVIRONMENTAL
- Automatic Window Defrost : Standard at Power-Up
- Temperature (Operating) : -25°C to +55°C
- Lightning Protection : Standard
- Sand & Dust : Mil-Std-810E
- Storage Temperature Range : -40°C to +85°C
- Salt Spray : IEC 60945
- Shock : 15 g vertical, 9 g horizontal
- EMI : IEC 60945
- Vibration : IEC 60945; MIL-STD-810E
- Wind : 100 knot (115.2 mph)
PAN-TILT FEATURES
- Pan Range : ±30° per key (Locked in at Installation)
- Tilt Range : +34°, -27° (Locked in at Installation)
IMAGING & OPTICAL
- E-Zoom : 2×
- Image Processing : FLIR Proprietary Digital Detail Enhancement
POWER
- Power : PoE injector required per IEEE 802.3af
- Power Consumption : 4.8 W nominal; 12.5 W max
FLIR MD324
Compact Fixed View Marine Thermal Camera
The MD-Series is an affordable, compact, fixed-mounted thermal night vision system that helps with steering around obstacles, collision avoidance, and finding people in the water at night. Simple to mount and easy to integrate into your existing electronics, MD-Series outputs standard analog video that can be easily displayed on almost any monitor at the helm or other locations on the vessel.
