HATTELAND® Series X MVD - 32.0 Inch
Featured Information
HATTELAND® Series X MVD - 32.0 Inch
SPESIFICATIONS
- TFT Technology : LED Backlight Technology, TFT Active-matrix, Widescreen, RGB Vertical Stripe, AHVA (Advanced Hyper Viewing Angles) LCD Technology
- Viewable Size and Active Area : 32.0 inch - 708.48 [27.89''] (H) x 398.52 [15.69''] (V) mm [inch]
- Native Resolution and Pixel Pitch : 3840 x 2160 (UHD, 4K) - 0.1845 (H) x 0.1845 (V) mm
- Aspect Ratio and Response Time : 16:9 - 12ms (typical) (G to G)
- Light Intensity and Contrast Ratio : 350 cd/m² (typ) - 1000:1 (typ)
- View Angle and Max Colors : 89 deg. (up/down/left/right) - 16.7 million
- Optimal Resolution and Hz : 3840 x 2160 @ 60 Hz
- Detectable Resolutions : VGA (640 x 350) to UHD (3840 x 2160)
- Composite Video Input(s) : None
- Supported Video Signals : None
- Storage Temperature : -30.0°C / -22.0°F to 70.0°C / 158.0°F, Humidity up to 95%
- IP Rating : Protection: IP66 front - IP22 rear (EN60529)
- Compass Safe Distance : Standard: 240.00 [94.49''] - Steering: 145.00 [57.09''] cm [inch]
- Type Approval, Testing and Certificates : IEC 60945 4th (EN 60945:2002), IACS E10, EU-RO-MR - Mutual Recognition, CCS - China Classification Society, ClassNK - Nippon Kaiji Kyokai, BV - Bureau Veritas, KR - Korean Register of Shipping, ABS - American Bureau of Shipping Shock: 5g/11ms Vibration: 0.7g (IEC 60945 / IACS E10) Air Pressure Maximum Altitude: Operating: 4000m - Storage: 12912m Air Pressure Maximum Altitude (Bonded): Operating: 3000m - Storage: 3000m
- Product Features : Full Dimming 0-100%, PIP (Picture In Picture)
- Power Specifications and Consumption : Multi-power 115/230VAC - 50/60Hz + 24VDC Operating: 65W (typ) - 156W (max)
- User Controls and Activity : Glass Display Control™ (GDC) IP66 with: Power On/Off, On Screen Display Menu*, Brightness Control (-/+), Hotkeys (left/right), Mode Status Indicators (ECDIS, Service), Buzzer (not visible), Light Sensor (not visible) *OSD Key Codes: 321=Get access to OSD, 362=Advanced Mode
- Connectors : • HDMI 1.4 Input: 2 x 19p HDMI (female) - Max 3840x2160@30Hz • HDMI 2.0 Input: 1 x 19p HDMI (female) - Max 3840x2160@60Hz • DP 1.2 Input: 1 x 20p DisplayPort (female) - Max 3840x2160@60Hz • SCOM+Touch: 1 x USB TYPE A Connector (female) • SCOM RS-422/485: 2 x 5-pin T. Block 3.81 non-isolated+Buzzer • SCOM Ethernet: 1 x RJ45 Connector • SCOM RS-232: 1 x 9p D-SUB (female) non-isolated • User Interface: 1 x 9p D-SUB (male) - Potentiometer Analog Input, User Brightness (BRT), I2C and +5VDC & 12VDC OUT • FW Update: 1 x USB TYPE A (female) for Firmware Update • AC Power IN: 1 x Std IEC Inlet • DC Power IN: 1 x 2-pin Terminal Block 5.08
- Product Dimensions and Weight : W:758.00 [29.84''] x H:500.00 [19.69''] x D:64.00 [2.52''] mm [inch] Weight: Approx. 17.0kg / 37.4lbs
- Product Carton Size and Weight : L:860.00 [33.86''] x W:180.00 [7.09''] x H:670.00 [26.38''] mm [inch] Weight: 19.0kg / 41.8lbs
- Factory Options : • Projected Capacitive Touch Screen (Multitouch,USB,Glove/Pen support) • Optical Bonding Technology • Color Calibrated models (ECDIS)
- Accessories : • HD CMB SX2-E1: 1 x Console Mount Kit. EN60945 Tested • HD TMB SX2-A2: 1 x Table Mount Bracket. EN60945 Tested • HD VED SX2-G1: 1 x VESA Adapter. Not EN60945 Tested • HD REM SX1-A1: 1 x External Remote Control, EN60945 Tested • P019761: 1 x IP66 Mount Gasket (EPDM),for Flush/Console mount
- Capabilities / Prepared for : • Tactor (Rotation Angle Value, X/Y Position, 1 x Button) supported Model • Active Stylus Pen Supported Model
- Operating Temperature : -15.0°C / 5.0°F to 55.0°C / 131.0°F, Humidity up to 95%
The 32 inch Series X MVD features 4K screen resolution and high-end panel technology, it provides unmatched viewing clarity in all light conditions. Its ultramodern approach represents the pinnacle of maritime display technology, making it the most advanced platform for the development of a new generation of sophisticated, function rich and user-friendly bridge technologies that demand only the best display solutions to ensure increased navigational safety and efficiency on the bridge. Approved for harsh maritime environments where reliability and long life time are key factors, the new 32 inch Series X MVD display is a robust, flexible and ergonomic solution, suitable for a wide range of bridge applications including ECDIS, radar, voyage planning, safety systems and tactical command & control platforms. Features include console or bracket mounting, an optional 40 point Multi-touch touch interface, optical bonding, multi-data input, built in On-Screen Display (OSD), full dimming and the option to be supplied calibrated for ECDIS.
