HATTELAND® Series X G2 - 17.0 Inch
Featured Information
HATTELAND® Series X G2 - 17.0 Inch
SPESIFICATION
- TFT Technology : Sunlight Readable - High Bright, LED Backlight Technology, TFT active-matrix liquid crystal panel, Optical Bonding Technology
- Viewable Size and Active Area : 17.0 inch - 337.92 [13.30''] (H) x 270.33 [10.64''] (V) mm [inch]
- Native Resolution and Pixel Pitch : 1280 x 1024 (SXGA) - 0.264 (H) x 0.264 (V) mm
- Aspect Ratio and Response Time : 5:4 - 30ms (typ)
- Light Intensity and Contrast Ratio : 1000 cd/m² (typ) - 800:1 (typ)
- View Angle and Max Colors : +/- 85° (6, 9 & 3 o'clock) +/- 60° (12 o'clock) (typ) 16.7 million
- Optimal Resolution and Hz : 1280 x 1024 @ 60 Hz
- Detectable Resolutions : 640 x 350, 640 x 480, 720 x 400, 800 x 600, 1024 x 768, 1280 x 1024
- Composite Video Input(s) : Composite (BNC)
- Supported Video Signals : Interlaced HDTV, NTSC, PAL and SECAM video, Composite Video
- Storage Temperature : -30.0°C / -22.0°F to +70.0°C / +158.0°F, Humidity up to 95%
- IP Rating : Protection: IP66 front - IP22 rear (EN60529)
- Compass Safe Distance : Standard: 100.00 [39.37''] - Steering: 70.00 [27.56''] cm [inch]
- Type Approval, Testing and Certificates : IEC 60945 4th (EN 60945:2002), IACS E10, EU-RO-MR - Mutual Recognition, CCS - China Classification Society, ClassNK - Nippon Kaiji Kyokai, KR - Korean Register of Shipping, ABS - American Bureau of Shipping Shock: 5g/11ms Vibration: 0.7g (IEC 60945 / IACS E10) Air Pressure Maximum Altitude: Operating: 4000m - Storage: 12912m Air Pressure Maximum Altitude (Bonded): Operating: 3000m - Storage: 3000m
- Product Features : Dimmable 0-100%, Multi-power AC & DC, PBP (Picture By Picture), PIP (Picture In Picture), Delivery includes an EPDM sealing gasket for IP66 console mount.
- Power Specifications and Consumption : Multi-power 100-240V AC - 50/60Hz + 24VDC 150W (max)
- User Controls and Activity : Glass Display Control™ (GDC) IP66 with: Power On/Off, On Screen Display Menu*, Brightness Control (-/+), Hotkeys (left/right), Mode Status Indicator (ECDIS, Service), Buzzer (through glass), Light Sensor (behind glass) *OSD Key Codes: 321=Get access to OSD, 362=Advanced Mode
- Connectors : • DVI-I IN: 2 x 29p DVI Female (or as VGA IN with adapter) • DP1.2 IN: 1 x 20p DisplayPort (female) • Comp. Video IN: 2 x BNC Connector (female) • SCOM RS-422/485: 2 x 5-pin Terminal Block 3.81, non-isolated+Buzzer • SCOM+Touch: 1 x USB TYPE A Connector (female) • SCOM Ethernet: 1 x RJ45 Connector • SCOM RS-232: 1 x 9p D-SUB (female) non-isolated+Buzzer • VGA OUT: 1 x 15p HD D-SUB (female) - Clone of VGA IN • Potmeter/User: 1 x 9p D-SUB (male) (Potentiometer IN, +5VDC OUT, BRT +/- IN) • AC Power IN: 1 x Std IEC Inlet • DC Power IN: 1 x 2-pin Terminal Block 5.08
- Product Dimensions and Weight : W:390.00 [15.35''] x H:351.00 [13.82''] x D:78.50 [3.09''] mm [inch] Approx. 6.8kg / 15.0lbs
- Product Carton Size and Weight : L:530.00 [20.87''] x W:200.00 [7.87''] x H:540.00 [21.26''] mm [inch] Approx. 9.1kg / 20.0lbs
- Factory Options : • Projected Capacitive Touch Screen (Multitouch,USB, Pen/Glove support) • Color Calibrated models (ECDIS) • 1 x Additional Composite Video IN (BNC) Connector
- Accessories : • HD CMB SX2-A1: 1 x Console Mount Kit. EN60945 Tested • HD TMB SX2-A1: 1 x Table Mount Bracket. EN60945 Tested • HD VED SX2-B1: 1 x VESA Adapter (75/75, 100/100 & 200/100mm) (not EN60945 Tested) • HD REM SX1-A1: 1 x External Remote Control, EN60945 Tested • HD 17COV SX1-A1: 1 x UV Sun Cover • P007130-1: 1 x IP66 Mount Gasket (EPDM), for Flush/Console mount
- Capabilities / Prepared for : None
- Operating Temperature : -15.0°C / 5.0°F to 55.0°C / 131.0°F, Humidity up to 95%
The Series X Generation 2 (G2) display range is a flexible monitor solution designed and type approved for the professional maritime segment, where reliability and long life time are key prerequisites for the industry. The product range combines stunning design and technology with innovative features and options, making it all that the integrator needs for top class type-approved marine systems. The multi-input MMD models provide a wide choice of display size and format for a multitude of shipboard applications, where combining data and video inputs to a single unit provides maximum flexibility. Be it for ship navigation, automation or security, this range with all it's possible options provides a robust and multipurpose platform from which to display and manage data and multiple camera or sensor videos. Series X Generation 2 (G2) displays feature Glass Display Control™, LED Backlight Technology, full dimming and multipower as standard, and can also accomodate and combine a number of options such as multi-touch screen, optical bonding and ECDIS calibration. By factory standards the 17 inch unit is ECDIS Compliant.
