HATTELAND® Series E - 13.3 Inch - IP22
Featured Information
HATTELAND® Series E - 13.3 Inch - IP22
SPESIFICATION
- TFT Technology : TFT Liquid Crystal Display module, VA (Vertical Alignment), a-si TFT Active Matrix, Widescreen, LED Backlight Technology
- Viewable Size and Active Area : 13.3 inch - 293.76 [11.57''] (H) x 165.24 [6.51''] (V) mm [inch]
- Native Resolution and Pixel Pitch : 1920 x 1080 (FHD) - 0.1529 (H) x 0.1529 (V) mm
- Aspect Ratio and Response Time : 16:9 - 25ms (typ) (Tr+Tf)
- Light Intensity and Contrast Ratio : 600 cd/m² (typ) - 600:1 (typ)
- View Angle and Max Colors : 85 deg. (up/down/left/right) - 16.7 million (24bit)
- Optimal Resolution and Hz : 1920 x 1080 @ 60 Hz
- Detectable Resolutions : • VGA : 640 x 480 (including 640 x 350) • SVGA : 800 x 600 (including 720 x 400) • XGA : 1024 x 768 • SXGA : 1280 x 1024 • UXGA : 1600 x 1200 • FHD : 1920 x 1080 [2] [2] Recommended for optimal picture quality [2] USB- C PD Supports DisplayPort signal - up to 1920 x 1080 (FHD)
- Composite Video Input(s) : None
- Supported Video Signals : None
- Storage Temperature : -20.0°C / -4.0°F to 60.0°C / 140.0°F Humidity up to 95%
- IP Rating : Protection: IP67 front - IP22 rear (EN60529)
- Compass Safe Distance : Standard: TBD - Steering: TBD cm [inch]
- Type Approval, Testing and Certificates : IEC 60945 4th (EN 60945:2002)*, IACS E10*, EU-RO-MR - Mutual Recognition*, KR - Korean Register of Shipping*, ABS - American Bureau of Shipping*, BV - Bureau Veritas*, CCS - China Classification Society*, ClassNK - Nippon Kaiji Kyokai* Air Pressure max Alt.: Operating: 3000m - Storage: 3000m *=pending
- Product Features : USB-C PD/DP Display, LED Backlight Technology, Full Dimming 100%, Low Power Consumption, Daisy Chain (MST) Capability, Superior Optical Bonding, Multi-Touch, AG Coated Front Glass
- Power Specifications and Consumption : • Single DC Power Option: 12-24VDC • USB-C PD Sink: 20VDC/3A (Requested) 16W (typ) - 24W (max) USB-C PD Sink: 60W (Requested) (USB-C PD Sink will request 20V/3A (60W) from source).
- User Controls and Activity : Glass Display Control™ (GDC) IP67 with: Power On/Off, Brightness Control (-/+), Light Sensor (not visible), Buzzer (not visible), DDC/CI over DP (over USB-C), SCOM over DP (over USB-C)
- Connectors : • USB-C Input: 1 x USB-C with DP, power (sink) and USB2.0 Female • USB-C Output: 1 x USB-C with DP and USB2.0 Female • USB: 1 x USB-C with USB2.0 Female • DC Input: 1 x 2-pin Terminal Block 5.08
- Product Dimensions and Weight : W:355.00 [13.98''] x H:248.50 [9.78''] x D:54.86 [2.16''] mm [inch] Approx. 2.3kg / 5.1lbs
- Product Carton Size and Weight : L:445.00 [17.52''] x W:195.00 [7.68''] x H:355.00 [13.98''] mm [inch] Weight approx: TBD
- Factory Options : • T21 Front • Customized Front
- Accessories : • HD CMB SX2-C1: 1 x Console Mount Kit. EN60945 Tested • VSD 203453-1: 1 x USB-C external cable for 4K@24b@60Hz, 2m • HD TMB SCM-A3: 1 x Table/Ceiling Mount Bracket. Not EN60945 Tested • HD VED SCM-L1: 1 x VESA Adapter (75/75,100/100). Not EN60945 Tested) • HD 13COV STD-A1: 1 x UV Sun Cover • P014441: 1 x IP66 Mount Gasket (EPDM), Flush/Console mount • HT DPUSB-2-USBC-A1: 1 x DP & USB2.0 (Female) to USB-C (Male) Adapter, 2m • HT HDMIUSB-2-USBC-A1: 1 x HDMI & USB2.0 (Female) to USB-C (Male) Adapter, 2m Please see user manual/datasheet/drawings for more information
- Capabilities / Prepared for : N/A
- Operating Temperature : -15.0°C / 5.0°F to 55.0°C / 131.0°F Humidity up to 95%
The Series E - HATTELAND® Single Cable Monitor (SCM) delivers a reliable all-in-one solution for diverse maritime applications and enables tangible cost savings for maritime technology and equipment manufacturers as well as systems integrators. The integrated nature of Series E Single Cable Monitors enables tangible cost savings for maritime technology and equipment manufacturers as well as systems integrators. The portfolio features a range of display sizes, new USB-C interface technology which carrying DP, power and USB signals, Daisy chain capability, which enables single cable operation. Providing full flexibility to integrate the highest quality displays in a wider range of maritime technology. Especially suited to developing new bridge solutions, Series E Monitors make it possible to continue improving safety and efficiency through safe navigation, while still retaining focus on quality and cost. Series E Single Cable Monitors also meet the same extreme quality standards as the proven Series X Monitor range and feature LED Backlight Technology, full dimming (0-100%) all as standard. In addition there are features such as USB-C PD Sink and optional DC input.
