SPECIFICATIONS

• Part Number :  BFLY-PGE-05S2C-CS
• Resolution :  808 × 608
• Frame Rate :  50
• Megapixels :  0.5
• Chroma :  Color
• Sensor Name :  Sony ICX693
• Sensor Type :  CCD
• Sensor Format :  1/3"
• Readout Method :  Global shutter
• Pixel Size :  6

FEATURES

• Exposure Range :  0.082 ms to 32 seconds
• Flash Memory :  512 KB non-volatile memory
• Frame Rate :  50
• Gain Range :  0 dB to 24 dB
• Image Buffer :  16 MB
• Image Processing :  Gamma, lookup table, hue, saturation, and sharpness
• Partial Image Modes :  Pixel binning, decimation, ROI
• Trigger Modes :  Standard, low smear, overlapped, multi-shot
• User Sets :  2 user configuration sets for custom camera settings

PHYSICAL

• ADC :  12-bit
• Auxiliary Output :  3.3 V, 120 mA maximum
• Chroma :  Color
• Dimensions [W x H x L] :  29 mm × 29 mm ×30 mm
• Interface :  GigE PoE
• Lens Mount :  CS-mount (5 mm C-mount adapter not included)
• Mass :  36 grams
• Megapixels :  0.5
• Operating Humidity :  20 to 80% (no condensation)
• Operating Temperature :  0° to 45°C

• Storage Temperature :  -30° to 60°C

COMPLIANCE & CERTIFICATIONS

• Compliance :  CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099.
• Machine Vision Standard :  GigE Vision v1.2
• Warranty :  3 years
