Grasshopper3 USB3
Grasshopper3 USB3
Grasshopper3 USB3
Grasshopper3 USB3
Model :GS3-U3-51S5C-C: 5.0 MP, 75 FPS, Sony IMX250, Color
Featured Information
Part Number :
GS3-U3-51S5C-C
Resolution :
2448 × 2048
Frame Rate :
75
GS3-U3-51S5C-C: 5.0 MP, 75 FPS, Sony IMX250, Color
Grasshopper3 USB3
SPECIFICATIONS
- Part Number : GS3-U3-51S5C-C
- Resolution : 2448 × 2048
- Frame Rate : 75
- Megapixels : 5
- Chroma : Color
- Sensor Name : Sony IMX250
- Sensor Type : CMOS
- Sensor Format : 2/3"
- Readout Method : Global shutter
- Pixel Size : 3.45
FEATURES
- Exposure Range : 0.006 ms to 32 seconds
- Flash Memory : 2 MB non-volatile memory
- Frame Rate : 75
- Gain Range : 0 dB to 48 dB
- Image Buffer : 128 MB
- Image Processing : Gamma, lookup table, and sharpness
- Partial Image Modes : Pixel binning, ROI
- Trigger Modes : Standard, bulb, overlapped, multi-shot
- User Sets : 2 user configuration sets for custom camera settings
PHYSICAL
- ADC : 10-bit, 12-bit
- Auxiliary Output : 3.3 V, 150 mA maximum
- Chroma : Color
- Dimensions [W x H x L] : 44 mm × 29 mm × 58 mm
- Interface : USB 3.1 Gen 1
- Lens Mount : C-mount
- Mass : 90 grams
- Megapixels : 5
- Non-isolated I/O Ports : 2 bi-directional
- Operating Humidity : 20 to 80% (no condensation)
- Serial Port : 1 (over non-isolated I/O)
- Storage Humidity : 20 to 95% (no condensation)
- Storage Temperature : -30° to 60°C
COMPLIANCE & CERTIFICATIONS
- Compliance : CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099
- Machine Vision Standard : USB3 Vision v1.0
- Warranty : 3 years
- Lens Mount : C-mount
- ADC : 10-bit, 12-bit
- Required Accessories : Lens, Cable, Host Adapter (USB 3.1 Gen 1)
PERFORMANCE
- Absolute Sensitivity Threshold (y) : 8.56 (Mode 0) / 4.36 (Mode 7)
- Dynamic Range dB : 65.41 (Mode 0) / 71.27 (Mode 7)
- Power Consumption : 4.5 W
- Quantum Efficiency Blue : 53 (Mode 0) / 53 (Mode 7) (% at 470 nm)
- Quantum Efficiency Green : 66 (Mode 0) / 67 (Mode 7) (% at 525 nm)
- Quantum Efficiency Red : 58 (Mode 0) / 58 (Mode 7) (% at 640 nm)
- Saturation Capacity (e-) : 10196 (Mode 0) / 10330 (Mode 7)
- Temporal Dark Noise (e-) : 4.97 (Mode 0) / 2.32 (Mode 7)
- Operating Temperature : 0° to 50°C
- Opto-isolated I/O Ports : 1 input, 1 output
- Part Number : GS3-U3-51S5C-C
- Pixel Size : 3.45
- Power Requirements : 5 V via USB3 or 8-24 V via GPIO (e×ternal power is recommended for this model)
- Readout Method : Global shutter
- Resolution : 2448 × 2048
- Sensor Format : 2/3"
- Sensor Name : Sony IMX250
- Sensor Type : CMOS
RECOMMENDED SYSTEM CONFIGURATION
- Accessories Included : Tripod Mount Adapter (ACC-01-0011)
- CPU : 3.1 GHz or equivalent CPU
- Hard Drive : 200 MB hard drive space
- Operating System : Windows or Linux (32–bit or 64–bit)
- Port : USB 3 Port
- RAM : 2 GB RAM or more
- Required Accessories : Lens, Cable, Host Adapter (USB 3.1 Gen 1)
GS3-U3-51S5C-C: 5.0 MP, 75 FPS, Sony IMX250, Color
Grasshopper3 USB3
The Grasshopper®3 camera line provides high-performance, high-quality imaging by combining FLIR expertise with the latest in CCD and CMOS technology.
