Model :ORX-10GS-89S6M-C: 8.9 MP, 93 FPS, Sony IMX255, Mono
Featured Information
Part Number :
ORX-10GS-89S6M-C
Resolution :
4096 × 2160
Frame Rate :
93
ORX-10GS-89S6M-C: 8.9 MP, 93 FPS, Sony IMX255, Mono
Oryx 10GigE
SPECIFICATIONS
- Part Number : ORX-10GS-89S6M-C
- Resolution : 4096 × 2160
- Frame Rate : 93
- Megapixels : 8.9
- Chroma : Mono
- Sensor Name : Sony IMX255
- Sensor Type : CMOS
- Sensor Format : 1"
- Readout Method : Global shutter
- Pixel Size : 3.45
FEATURES
- Acquisition Modes : Continuous Single Frame Multi Frame
- Exposure Range : 5 µs to 30 seconds
- Flash Memory : 4 MB non-volatile memory
- Frame Rate : 93
- Gain Range : 0 dB to 47 dB
- Image Buffer : 240 MB
- Image Processing : Gamma, lookup table, and sharpness
- Partial Image Modes : Pixel binning, decimation, ROI
- User Sets : 2 user configuration sets for custom camera settings
PHYSICAL
- ADC : 8-bit, 10-bit, 12-bit
- Auxiliary Output : 3.3 V, 120 mA maximum
- Chroma : Mono
- Dimensions [W x H x L] : 60 mm × 60 mm × 64 mm
- Interface : 10 GigE
- Lens Mount : C-mount
- Mass : 386 grams
- Megapixels : 8.9
- Non-isolated I/O Ports : 2 bi-directional
- Operating Humidity : 20 to 80% (no condensation)
- Sensor Type : CMOS
- Storage Humidity : 20 to 95% (no condensation)
- Storage Temperature : -30° to 60°C (ambient)v
COMPLIANCE & CERTIFICATIONS
- Compliance : CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099.
- Machine Vision Standard : GigE Vision v1.2
- Warranty : 3 years
- Lens Mount : C-mount
- ADC : 8-bit, 10-bit, 12-bit
- Required Accessories : Lens, Cable, Host Adapter (10GigE), Power Supply (ACC-01-9013)
PERFORMANCE
- Absolute Sensitivity Threshold (y) : 4.72
- Dynamic Range dB : 70.97
- Quantum Efficiency : 62.99 (530nm)
- Saturation Capacity (e-) : 10514
- Temporal Dark Noise (e-) : 2.47
- Operating Temperature : 0° to 70°C (case)
- Opto-isolated I/O Ports : 1 input, 1 output
- Part Number : ORX-10GS-89S6M-C
- Pixel Size : 3.45
- Power Consumption [Maximum] : 15 W (11 W nominal)
- Power Requirements : 12-24 V, via GPIO interface
- Readout Method : Global shutter
- Resolution : 4096 × 2160
- Sensor Format : 1"
- Sensor Name : Sony IMX255
RECOMMENDED SYSTEM CONFIGURATION
- CPU : 3.1 GHz or equivalent CPU
- Hard Drive : 200 MB hard drive space
- Operating System : Windows or Linux (32–bit or 64–bit)
- Port : Gigabit Ethernet Port
- Power Sourcing Equipment : Camera Power Supply (12v 1.5A, 12–pin Hirose)
- RAM : 2 GB RAM or more
- Required Accessories : Lens, Cable, Host Adapter (10GigE), PowerSupply (ACC-01-9013 )
ORX-10GS-89S6M-C: 8.9 MP, 93 FPS, Sony IMX255, Mono
Oryx 10GigE
The award-winning Oryx 10GigE camera family allows systems designers to take advantage of the latest sensors by supporting transfer speeds of up to 10 Gbit/s enabling capture of 4K resolution, 12-bit images at over 60 FPS. Oryx features include IEEE1588 clock synchronization and full compatibility with several popular third-party software supporting GigE Vision. Oryx’s 10GBASE-T interface is a proven and widely deployed standard that provides reliable image transfer at cable lengths over 50 meters on inexpensive CAT6A, and up to 30 meters on CAT5e.
