Model :ORX-10G-71S7M-C: 7.1 MP, 112 FPS, Sony IMX420, Mono

Featured Information

Part Number :
ORX-10G-71S7M-C
Resolution :
3208 × 2200
Frame Rate :
112
Product thumb
ORX-10G-71S7M-C: 7.1 MP, 112 FPS, Sony IMX420, Mono
Oryx 10GigE

SPECIFICATIONS

  • Part Number :  ORX-10G-71S7M-C
  • Resolution :  3208 × 2200
  • Frame Rate :  112
  • Megapixels :  7.1
  • Chroma :  Mono
  • Sensor Name :  Sony IMX420
  • Sensor Type :  CMOS
  • Sensor Format :  1.1"
  • Readout Method :  Global shutter
  • Pixel Size :  4.5

FEATURES

  • Acquisition Modes :  Continuous Single Frame Multi Frame
  • Exposure Range :  10 µs to 30 seconds
  • Flash Memory :  4 MB non-volatile memory
  • Frame Rate :  112
  • Gain Range :  0 db to 47 dB
  • Image Buffer :  240 MB
  • Image Processing :  Gamma, lookup table, pixel correction, target grey value, and sharpness
  • Partial Image Modes :  Pixel binning, decimation, ROI
  • User Sets :  2 user configuration sets for custom camera settings

PHYSICAL

  • ADC :  8-bit, 10-bit, 12-bit
  • Auxiliary Output :  3.3 V, 120 mA maximum
  • Chroma :  Mono
  • Dimensions [W x H x L] :  60 mm × 60 mm × 100 mm
  • Interface :  10 GigE
  • Lens Mount :  C-mount
  • Mass :  500 grams
  • Megapixels :  7.1
  • Non-isolated I/O Ports :  2 bi-directional
  • Operating Humidity :  20 to 80% (no condensation)

  • Serial Port :  1 (over non-isolated I/O)
  • Storage Humidity :  20 to 95% (no condensation)
  • Storage Temperature :  -30° to 60°C

COMPLIANCE & CERTIFICATIONS

  • Compliance :  CE, FCC, KCC, RoHS, REACH. The ECCN for this product is: EAR099.
  • Machine Vision Standard :  GigE Vision v1.2
  • Machine Vision Standard :  3 years

  • Lens Mount :  C-mount
  • ADC :  8-bit, 10-bit, 12-bit
  • Required Accessories :  Lens, Cable, Host Adapter (10GigE), Power Supply (ACC-01-9013)

PERFORMANCE

  • Absolute Sensitivity Threshold (y) :  4.74 (HCG) / 9.42 (LCG)
  • Dynamic Range dB :  70.59 (HCG) / 71.74 (LCG)
  • Power Consumption :  13.6 W (13.2 W nominal); GPIO power only
  • Quantum Efficiency :  67 (HCG) / 68 (LCG) @530 nm
  • Saturation Capacity (e-) :  10692 (HCG) / 24802 (LCG)
  • Temporal Dark Noise (e-) :  2.66 (HCG) / 5.92 (LCG)

  • Operating Temperature :  0° to 50°C
  • Opto-isolated I/O Ports :  2 input, 2 output
  • Part Number :  ORX-10G-71S7M-C
  • Pixel Size :  4.5
  • Power Requirements :  12-24 V, via GPIO interface
  • Readout Method :  Global shutter
  • Resolution :  3208 × 2200
  • Sensor Format :  1.1"
  • Sensor Name :  Sony IMX420
  • Sensor Type :  CMOS

RECOMMENDED SYSTEM CONFIGURATION

  • CPU :  4th Generation Intel Core i7 (or newer)
  • Hard Drive :  200 MB hard drive space
  • Operating System :  Windows or Linux (32–bit or 64–bit)
  • Port :  10GBASE–T Ethernet Port
  • Power Sourcing Equipment :  Camera Power Supply (12v 1.5A, 12–pin Hirose)
  • RAM :  8 GB RAM or more (dual channel)
  • Required Accessories :  Lens, Cable, Host Adapter (10GigE), Power Supply (ACC-01-9013)

Product thumb
ORX-10G-71S7M-C: 7.1 MP, 112 FPS, Sony IMX420, Mono
Oryx 10GigE

The award-winning Oryx 10GigE camera family allows systems designers to take advantage of the latest sensors by supporting transfer speeds of up to 10 Gbit/s enabling capture of 4K resolution, 12-bit images at over 60 FPS. Oryx features include IEEE1588 clock synchronization and full compatibility with several popular third-party software supporting GigE Vision. Oryx’s 10GBASE-T interface is a proven and widely deployed standard that provides reliable image transfer at cable lengths over 50 meters on inexpensive CAT6A, and up to 30 meters on CAT5e.
