FLIR Elara™ R-190

Commercial Ground Radar
FLIR Elara™ R-190
Commercial Ground Radar

Featured Information

I/Os :
RJ45 Ethernet, 10-pin Terminal Block
Input Voltage :
12V DC, 24V AC, and POE+
Power Consumption :
7.5W
Product thumb
FLIR Elara™ R-190
Commercial Ground Radar

SPECIFICATIONS

  • I/Os :  RJ45 Ethernet, 10-pin Terminal Block
  • Input Voltage :  12V DC, 24V AC, and POE+
  • Power Consumption :  7.5W
  • Protocols :  AXML, ONVIF, FLIR Nexus SDK, FLIR Nexus CGI
  • RF Transmit Power :  14dBm (0.025W)
  • Weight :  5.1lbs (2.3kg)

OPTIONAL ACCESSORIES

  • Pole Mount
  • Corner Mount
  • 180° Dual Wall Mount
  • PoE Power Supply

IMAGING & OPTICAL

  • Field of View [H x V] :  90x20
  • Refresh Rate :  Up to 10Hz

PERFORMANCE

  • Range Accuracy :  <1m

OVERVIEW

  • Dimensions (H x W x D) :  6.3 × 6.3 × 7.7 in (161 × 161 × 195 mm)
  • Non-Operating Temperature :  -50°C to 85°C
  • Pan Range :  ± 43°
  • Tilt Range :  +30° / -60°

ENVIRONMENTAL

  • IP Rating :  IP66
  • Operating Temperature :  -40°C to 70°C

MEASUREMENT & ANALYSIS

  • Angular Accuracy :  0.6m
  • Coverage Area :  3 acres / 12,000m2 (Human Detection)
  • Frequency Range :  24.000-24.250GHz
  • Human Detection Range :  125m
  • Min Target Detection Speed :  0.2m/s
  • Radar Targets :  Max 32
  • Range Resolution :  1.5m
  • Target Information :  GPS coordinates, velocity, RCS, range, azimuth angle/direction, heading, course/track, target ID
  • Vehicle Detection Range :  300m

SHIPPING INFORMATION

  • Box Contents :  Radar, Back Box, Back Box Cover, Back Box Side Cover, Wall Mount Plate, RJ45 Cover, Screw Driver, Hex Wrench, 10-Pin I/O Connector

Product thumb
FLIR Elara™ R-190
Commercial Ground Radar

The FLIR Elara R-290 is a compact ground radar used to detect and provide early warning of intruders as part of a larger video surveillance system. Radars can track targets in all weather and lighting conditions and dynamically map them in real time for position intelligence. The Elara R-290 features a 90-degree field of view and up to 400-meter range for vehicle tracking and 200-meter range for human tracking, providing wide-area protection and situational awareness beyond the fence line. With simultaneous tracking of up to 32 targets and geolocation capability, the Elara R-290 can activate alarms and guide PTZ cameras for visual verification to maximize security coverage and increase the amount of time available to react to a threat.
