Dual-Sensor Temperature-Measurement Pan/Tilt
Dual-Sensor Temperature-Measurement Pan/Tilt
Model :FLIR A310pt, 45° PAL
Featured Information
Size (L × W × H) :
460 × 467 × 326 mm (18,1 × 18,4 × 12,8 in)
Weight :
17,8 kg (39,3 lb.)
Detector Type :
Focal Plane Array (FPA), uncooled microbolometer
FLIR A310pt, 45° PAL
Dual-Sensor Temperature-Measurement Pan/Tilt
SPESIFICATIONS
- Size (L × W × H) : 460 × 467 × 326 mm (18,1 × 18,4 × 12,8 in)
- Weight : 17,8 kg (39,3 lb.)
- Detector Type : Focal Plane Array (FPA), uncooled microbolometer
- Focal Plane Array (FPA) : 1/4” Exview HAD CCD
- Field of View (FOV) : 45° × 33.8°
- IR Resolution : 320 × 240 pixel
- Thermal Sensitivity/NETD : < 0.05°C @ +30°C (+86°F) / 50 mK
- Focal Length : 9,66 mm (0,38 in)
- Detector Pitch : 25 µm
- Ethernet : Control, result and image
FLIR A310pt, 45° PAL
Dual-Sensor Temperature-Measurement Pan/Tilt
Security professionals around the world have been using FLIR thermal cameras for perimeter and critical asset security for years. Facility Operations and Safety personnel have been using FLIR cameras to gather non-contact temperature measurements and condition monitoring data for decades. A310F and A310PT cameras are the first in the world to combine thermal and visible light video security imaging with automated safety monitoring based on the detection of temperature measurement thresholds.
