Thermal Security Camera
Thermal Security Camera
Model :FLIR FC-617O, 640 x 480, 17° FOV, NTSC
Featured Information
Detector Type :
Long-Life, Uncooled VOx Microbolometer
Dimensions (L x W x H) :
Without sunshield: 259 x 114 x 106 mm/10.2 x 4.5 x 4.2 in; With sunshield: 282 x 129 x 115 mm/11.1 x 5.1 x 4.5 in
Effective Resolution :
307200
FLIR FC-617O, 640 x 480, 17° FOV, NTSC
Thermal Security Camera
GENERAL
- Detector Type : Long-Life, Uncooled VOx Microbolometer
- Dimensions (L x W x H) : Without sunshield: 259 x 114 x 106 mm/10.2 x 4.5 x 4.2 in; With sunshield: 282 x 129 x 115 mm/11.1 x 5.1 x 4.5 in
- Effective Resolution : 307200
- E-Zoom : 4x continuous E-Zoom
- Focus Range : Athermalized, Focus-Free
- Power Consumption : Source POE (802.3af) POE+ (802.3at) 12VDC 24VDC 24VAC(VA) Heater off <5.5W <5.5W <5.5W <5.5W <8W Heater on (@ 100%) N/A <25W <25W <25W <32W
- Surge Immunity on AC Power Lines : EN 55024: 2010 and 55022: 2010 to 4.0kV on AC aux power lines; EN 50130-4:2011; IEC 62599-2:2010
- Surge Immunity on Signal Lines : EN 55024: 2010 and 55022: 2010 to 4.0kV
- Warranty : Camera: 3 Years Sensor: 10 Years
- Weight : 2.2kg (4.75 lbs.)
SYSTEM INTEGRATION
- Analog Video Output Composite : 1Vp-p (PAL or NTSC), 1 x BNC 75Ω
- Control Input/Output : 1x Dry Contact in; 1x Relay Out (rated load 0.025A@ 5VDC)
- Ethernet : 10/100 Mbps
- External Analytics Compatible : Yes
- Network APIs : FLIR SDK FLIR CGI ONVIF Profile S
- Streaming Resolution : D1: 720 × 576 4CIF: 704 × 576 Native: 640 × 512 Q-Native: 320 × 256 CIF: 352 × 288 QCIF: 176 × 144
- Supported Protocols : IPV4, HTTP, Bonjour, UPnP, DNS, NTP, RTCP, TCP, UDP, ICMP, IGMP, DHCP, ARP, SCP, FTP, RTP/RTSP, Unicast/Multicast, TCP/IP, HTTP, IEEE 802.1X
- Video Over Ethernet : Two independent channels of H.264 (Restricted VBR and CBR,10kbps-4Mbps, MPEG4, and MJPEG)
VIDEO & RECORDING
- Composite Video NTSC or PAL : Hybrid system with IP & analog video
- Local Storage : Support for 32GB SD Card (not supplied)
COMPLIANCE & CERTIFICATIONS
- Approvals : CE: EN55032; FCC 47 CFR Part 15, Subpart B, Class A (within CISPR 22:2008 Class A limits)
- Certifications : IEC 60068-2-1:2007; IEC 60068-2-2:2007; ISTA-1A; IEEE 802.1x
- Compliance : RoHS Directive 2011/65/EU; WEEE 2012/19/EU
ENVIRONMENTAL
- Humidity : 0-95% relative humidity
- IP Rating (dust & water ingress) : IP66 & IP67
- Operating Temperature Range : -50°C to 70°C/-58°F to 158°F (Continuous Operation) -40°C to 70°C /-40°F to 158°F (Cold Start)
- Shock : MIL-STD-810G ''Transportation''
- Storage Temperature Range : -50°C to 85°C/-58°F to 185°F
- Vandal Resistance : IK10 (except Windows)
- Vibration : IEC 60068-2-27
THERMAL CAMERA
- Image Uniformity Optimization : Automatic Flat Field Correction (FFC); Thermal and Temporal Triggers
- Lens : 13/19/35mm
- Pixel Pitch : 17 µm
- Thermal AGC Modes : Auto AGC, Manual AGC, Plateau Equalization AGC, Linear AGC, Auto Dynamic Detail Enhancement (DDE), Max Gain Setting
- Thermal AGC Region of Interest [ROI] : Default, Presets and User definable to insure optimal image quality on subjects of interest
- Thermal Frame Rate : NTSC: 30 Hz - PAL: 25 Hz / 8.3 Hz
VISIBLE CAMERA
- Array Format : 640 × 480
- Field of View (FOV) : 17° × 14°
- f-number : f/1.1
- Focal Length : 35 mm
- Sensitivity : <35mK for F# 1.0 optics
- Spectral Range : 7.5 µm to 13.5 µm
FLIR FC-617O, 640 x 480, 17° FOV, NTSC
Thermal Security Camera
The Elara™ FC-Series O thermal security camera is one of FLIR’s premium thermal security cameras for perimeter protection. The Elara FC-Series O integrates with external video analytics devices, such as FLIR’s TRK or third party solutions, to classify human or vehicular intrusions. The Elara FC-Series O also offers a wide range of high-performance lenses, with a choice of resolutions, offering greater flexibility for tailoring security systems to specific site conditions.
