FLIR M500

Ultra High Performance Multi-Sensor Camera System

FLIR M500

Ultra High Performance Multi-Sensor Camera System

Featured Information

Automatic Window Defrost :

Standard at Power-Up

EMI :

IEC 60945

Lightning Protection :

Standard

FLIR M500

Ultra High Performance Multi-Sensor Camera System

ENVIRONMENTAL

Automatic Window Defrost : Standard at Power-Up
EMI : IEC 60945
Lightning Protection : Standard
Operating Temperature Range : -13°F to +131°F (-25°C to +55°C)
Salt Mist : IEC60945
Sand & Dust Ingress : Mil-Std-810E
Shock : 15 g vertical, 9 g horizontal
Vibration : IEC 60945; MIL-STD-810E
Water Ingress : IPX 6
Storage Temperature Range : -56° F to + 176°F (-50°C to +80°C)

IMAGING & OPTICAL

Video Tracking : Yes

RANGE PERFORMANCE

Detect a 30-foot Vessel : 5.0nm (9260m)
Detect Human Sized Target : 2.0nm (3625m)
NATO Target 2.3m x 2.3m at 50 Pct. : 3.5nm (6480m)

SYSTEM SPECIFICATIONS

Analog Video Connector Types : F-type BNC with BNC-to-RCA adapter included for video out
Analog Video Output : NTSC or PAL, 30 Hz or <9 Hz
Firefighter Mode : No
Gyro Stabilized : Yes
HD-SDI Lossless Video Output : Yes
Network Video Output : Four, Independent H.264 Network Video Streams
Pan-Tilt Adjustment Range : 360° Continuous Pan, ±90° Tilt
Power Consumption : 250 W (max w/heater)

VISIBLE CAMERA

Lines of Resolution : Up to 1920 x 1080 @ 30fps
Minimum Illumination : 0.1 lux (ICR off, slow shutter off, high sensitivity off) / 0.006 lux (ICR on, slow shutter off, high sensitivity off)
Visible Detector Type : 1/2.8” Exmor R CMOS
Visible E-Zoom : 12x
Visible Field of View : Optical 63.7° x 35.8° WFOV to 2.3° x 1.29° NFOV
Visible Focal Length : 129 mm to 4.3 mm
Zoom : 30× Optical Zoom

Wind : 100 knot (115.2 mph)

PHYSICAL

Power Requirements : 12 to 24vDC (24vDC recommended)
Size : Camera: 10.8” (273mm) x 15.7” (398mm) / Camera with Top-Down Riser: 12.8” (324mm) x 18.1” (459mm)
Weight : 32 lb (14.5 kg) (w/o top-down riser)

SPOTLIGHT SPECIFICATIONS

Type Lumens and Beam : LED, 580 Lumens, 5° Divergence Angle

THERMAL CAMERA

Image Processing : FLIR Proprietary Digital Detail Enhancement
Optical Zoom : 1x to 14x (continuous)
Thermal Detector Type : Cooled MWIR InSb 640x512 Focal Plane Array
Thermal E-Zoom : 4x
Thermal Field of View : Optical 28° x 21° WFOV to 2° x 1.5° NFOV
Thermal Focal Length : 19 mm (Wide) to 275 mm (Narrow)
Video Refresh Rate : 25 Hz (PAL) / 30 Hz (NTSC)

FLIR M500

Ultra High Performance Multi-Sensor Camera System

M500 Series Operator's Manual

The gyro-stabilized FLIR M500 cooled thermal camera is our most technologically-advanced M-Series pan and tilt camera ever. Designed around a cryogenically-cooled 640 x 512 pixel Mid Wave Infrared (MWIR) thermal sensor, the FLIR M500 excels at both short and ultra-long range target detection and identification. It features a 14X continuous optical thermal zoom, a color HD camera with 30x zoom, an LED spot-beam, video tracking and radar integration.
