USS-EDGE-POE-16TB

Compact IP Video Appliance with Built-in PoE

Compact IP Video Appliance with Built-in PoE

Model :USS-EDGE-POE-16TB

Featured Information

Dimensions :

43.9 x 220 x 244.3 mm (1.72 x 8.66 x 9.62 in)

Form Factor :

Small and compact Form Factor with 8-port POE switch

Memory :

8GB DDR4

Compact IP Video Appliance with Built-in PoE

GENERAL

Dimensions : 43.9 x 220 x 244.3 mm (1.72 x 8.66 x 9.62 in)
Form Factor : Small and compact Form Factor with 8-port POE switch
Memory : 8GB DDR4
Monitoring : Up to 280 FPS at 1080p
Operating System : Microsoft® Windows 10 IoT Enterprise 64 bit
Power Consumption : 80W min, 200W max, POE Power 120W
Power over Ethernet (PoE) : 8 x 10/100 RJ-45 ports
Power Supply : 200W; 100 to 240 VAC, 50/60 Hz, Single non-redundant power supply
Processor : Intel® Core™ Skylake i5-6500
Weight : Max Weight: 2.5 kg (5.5 lb)

ENVIRONMENTAL

Operating Temperature : 0°C to 40°C (32°F to 104°F)

UI-UX

Video Output : 2 x Standard HDMI, 1 x Display Port (Only 2 are supported simultaneously)

COMPLIANCE & CERTIFICATIONS

Certifications : UL, CE, FCC, LVD
Warranty : 3 years

SYSTEM INTEGRATION

Alarm I/O : 4 x alarm-in; 4 x alarm-out
Audio : Via HDMI or 3.5mm audio jack 1 x Mic-in / 1 x Headphone-out
Networking : Dual NIC, 2 x 10/100/1000 Mbps RJ-45
USB Port : 2 x USB 3.0, 1x eSata

VIDEO & RECORDING

Hard Drive : 2.5” SSD 128GB for Operating System and VMS Software
Hard Drive Storage : 16TB 3.5” SATA
Recording : 120 Mbps

USS-EDGE-POE-16TB

Compact IP Video Appliance with Built-in PoE

The FLIR USS Edge Appliance is a compact video appliance ideal for mobile security deployments, including mass transportation, marine applications, and mobile command centers. Equipped with an eight-port PoE switch, up to 16TB of video storage, and preloaded United VMS software, the USS Edge Appliance is an enterprise-grade solution that can be used as an independent VMS or to extend security systems across multiple locations.
