FLIR Elara DX-Series
320 x 240, 6 ° FOV
FLIR Elara DX-Series
320 x 240, 6 ° FOV
Model :FLIR DX-306
Featured Information
Detector Type :
Long-Life, Uncooled VOx Microbolometer
Focus Range :
Athermalized, Focus-Free
Input Voltage :
24 VAC(±10%) Universal POE injector
FLIR DX-306
320 x 240, 6 ° FOV
GENERAL
- Detector Type : Long-Life, Uncooled VOx Microbolometer
- Focus Range : Athermalized, Focus-Free
- Input Voltage : 24 VAC(±10%) Universal POE injector
- Thermal Spectral Range : 7.5 μm to 13.5 μm
- Zoom : Visible: Optical Zoom: 31
MEASUREMENT & ANALYSIS
- Programmable Presets : 256
SYSTEM INTEGRATION
- Ethernet : 10/100/1000 Mbps
- Network APIs : FLIR SDK, FLIR CGI, ONVIF Profile S
- Streaming Resolution : Thermal: QVGA to VGA Visible: VGA to 4k
- Supported Protocols : IPV4, HTTP, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP
VIDEO & RECORDING
- Video Compression : Thermal: One channel of H.264 & M-JPEG Visible: Two independent channels of H.264 & M-JPEG
- Video Image Uniformity Optimization : Automatic Flat Field Correction (FFC) - Thermal and Temporal Triggers
ENVIRONMENTAL
- Humidity : 0-95% relative
- IP Rating (dust & water ingress) : IP66
- Operating Temperature Range : -40°C to 60°C
- Shock : IEC 60068-2-27
- Storage Temperature : -55°C to 85°C
- Vibe : IEC 60068-2-64
PTZ
- Pan Speed : Continuous 360° 0.1° to 90° /sec
- Tilt Speed : -10° to 190° 0.1° to 60°/sec
THERMAL CAMERA
- Optical Characteristics : FOV: 6° × 5° Focal Length: 36 mm
- Pixel Pitch : 12 µm
- Thermal Frame Rate : NTSC: 30 Hz or PAL: 25 Hz / 8.3 Hz
- Thermal Image Settings : Auto AGC, Dynamic Detail Enhancement (DDE), Brightness, Sharpness, Contrast
VISIBLE CAMERA
- AGC : Default, Presets and User definable to insure optimal image quality on subjects of interest
- Array Format : 320 × 240
- Electronic Zoom : Continuous E-Zoom to 4×
- Focal Length : 6.5mm - 202mm
- Lens Field of View : Visible: HFOV: 61.8° - 2.15° VFOV: 36.65° - 1.2°
- Sensitivity : Visible: Color: 0.25 Lux (@ (f1.6 AGC On, 30FPS) B/W: 0.10 Lux (@ (f1.6 AGC On, 30FPS)
FLIR DX-306
320 x 240, 6 ° FOV
The FLIR Elara™ DX-Series multispectral pan/tilt/zoom (PTZ) security camera provides full situational awareness in the most punishing environments. Combining thermal and visible light imagers, the Elara DX-Series gives operators the ability to monitor large areas in complete darkness, glaring light, and adverse weather. The exceptional detection and identification capabilities of multispectral cameras help integrators provide solutions for challenging imaging problems at critical infrastructure sites and remote facilities.
