FLIR Elara FB-Series O

Thermal Bullet Camera

Thermal Bullet Camera

Model :FLIR FB-695-O, 95 ° FOV, 12µm

Featured Information

Detector Type :

Long-Life, Uncooled VOx Microbolometer

Dimensions (L x W x H) :

285 x 96 x 94 mm/11.1 x 3.8 x 3.7 With sunshield and fully extended mounting arm

Effective Resolution :

307,200 pixels

FLIR FB-695-O, 95 ° FOV, 12µm

Thermal Bullet Camera

GENERAL

Detector Type : Long-Life, Uncooled VOx Microbolometer
Dimensions (L x W x H) : 285 x 96 x 94 mm/11.1 x 3.8 x 3.7 With sunshield and fully extended mounting arm
Effective Resolution : 307,200 pixels
Focus Range : Athermalized, focus-free
Input Voltage : 12 VDC 24VAC PoE
Power Consumption : 12V DC: 17 W (maximum with heaters) / 24V AC : 13 VA (maximum with heaters) 24V DC : 13 W (maximum with heaters) / PoE: 13 W
Focal Length : 4,9 mm
Sensitivity : <50mK

SYSTEM INTEGRATION

Ethernet : 10/100 Mbps
External Analytics Compatible : Yes
Network APIs : Nexus SDK for comprehensive system control and integration; Nexus CGI for http command interfaces; ONVIF Profile S
Supported Protocols : IPV4, HTTP, Bonjour, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP

VIDEO & RECORDING

Composite Video NTSC or PAL : Hybrid system with IP & analog video
Digital Video Compression : Two independent channels of H.264 and MJPEG
Streaming Resolution PAL/NTSC : VGA: 640x480 & QVGA: 320x240

ENVIRONMENTAL

Humidity : 10%-90% relative humidity
IP Rating (dust & water ingress) : IP66
Operating Temperature Range : -40° to 50° C (-40° to 122° F) Cold Start
Regulatory : FCC Part 15 (Subpart B, Class A), CE marked, EN55032, EN55024, RoHS, WEEE
Storage Temperature Range : -40°C to 70°C (-40°-158°F)

THERMAL CAMERA

Image Uniformity Optimization : Automatic Flat Field Correction (FFC) - Thermal and Temporal triggers
Pixel Pitch : 12 um
Thermal AGC Region of Interest [ROI] : Default, Presets and User Defined for optimal image quality of subjects of interest
Thermal Image Settings : Auto AGC, Dynamic Detail Enhancement (DDE), Brightness, Sharpness, Contrast

VISIBLE CAMERA

Array Format : 640 × 480
Field of View (FOV) : 95°
f-number : F1.1
Focal Length : 4.9 mm
Sensitivity : <50mK
Spectral Range : 8 µm to 14 µm

FLIR FB-695-O, 95 ° FOV, 12µm

Thermal Bullet Camera

Flir FB Series User Manual

The compact FLIR Elara™ FB-Series O thermal security camera delivers industry-leading thermal imaging for perimeter and wide area protection around the clock. The camera also offers "plug-and-play" compatibility with external video analytics and major VMS suppliers, including FLIR United VMS, for additional functionality and a flawless user experience.
