FLIR Vue Pro

Thermal Camera for Drones

FLIR Vue Pro

Thermal Camera for Drones

Model :Flir Vue Pro 640, 69° FOV, 9mm, 30Hz

Featured Information

Analog Video Output :

Yes

Flir Vue Pro 640, 69° FOV, 9mm, 30Hz

Thermal Camera for Drones

CONNECTIONS & COMMUNICATIONS

Analog Video Output : Yes

ENVIRONMENTAL & APPROVALS

Non-Operating Temperature Range : -55°C to +95°C
Operating Temperature Range : -20°C to +50°C
Operational Altitude : +40,000 feet

Thermal Imager : Uncooled VOx Microbolometer

OPTIONAL POWER & HDMI VIDEO MODULE

Input Power Range : 5 VDC – 28 VDC
Reverse Polarity Protection : Yes

ELECTRICAL

Input Voltage : 4.8 - 6.0 VDC
Power Dissipation [peak] : 2.1 W (3.9 W)

IMAGING & OPTICAL

Color Palettes : Yes – Adjustable in App and via PWM
Frame Rate : 30 Hz (NTSC); 25 Hz (PAL)
HDMI Output : 1280x720 @ 50hz, 60hz
Image Optimization for sUAS : Yes
Lens Options : 9 mm; 69° × 56°
Lens Options [FOV for NTSC Analog Output] : 9 mm; 62° × 49°
Scene Presets & Image Processing : Yes – Adjustable in App
Sensor Resolution : 640 × 512
Invertable Image : Yes – Adjustable in App
Spectral Band : 7.5 - 13.5 µm

MECHANICAL

Precision Mounting Holes : Two M2x0.4 on each of two sides & bottom One 1/4-20 threaded hole on top
Size : 2.26 x 1,75 (lens included)
Weight : 3.25 - 4 oz (Configuration Dependant)
Zoom : Yes – Adjustable in App and via PWM

Flir Vue Pro 640, 69° FOV, 9mm, 30Hz

Thermal Camera for Drones

Designed for professional use, FLIR Vue Pro is more than a thermal camera, it is a thermal measurement instrument and data recorder that adds tremendous value to your sUAS operations and services.
