XSONIC Airmar PM275LH-W Transducer

Featured Information

Ideal for marking baitfish and game fish in shallow water depths of 300ft - 600ft

Depth and fast-response water temperature sensor

Low Frequency : CHIRPS between 42 kHz - 65 kHz with a beam width of 25° to 16°

XSONIC Airmar PM275LH-W Transducer

FEATURES :

Ideal for marking baitfish and game fish in shallow water depths of 300ft - 600ft
Depth and fast-response water temperature sensor
Low Frequency : CHIRPS between 42 kHz - 65 kHz with a beam width of 25° to 16°
High frequency : CHIRPS between 150 kHz - 250 kHz with a fixed 25° beam width
Total bandwidth of 123 kHz from a single transducer
Covers popular fishing frequencies of 50 kHz and 200 kHz, along with everything else in the bandwidth
Dual Black 9 pin connectors

Cable Length : 10 m (33.0 ft)
Hull Type : Fiberglass or wood
Boat Size : 8 m (25 ft) and up

XSONIC Airmar PM275LH-W Transducer

These transducers, offering a high-frequency range of 150-250 kHz and a fixed 25° beam width, are truly broadband. The PM275LH-W is a pocket or keel-mounted CHIRP transducer, ideal for sportfishing vessels 8 m (25 ft) and up. This dual-channel transducer combines Low CHIRP frequencies to accurately track the bottom in deep water, with High CHIRP at a constant 25° beam width for the best resolution and coverage in the upper water column and in shallower depths.
