Genie Nano-CXP M6200

MORE PIXELS, MORE PERFORMANCE, SAME NANO QUALITY

MORE PIXELS, MORE PERFORMANCE, SAME NANO QUALITY

Model :Genie Nano-CXP M6200

Featured Information

Part Number :

G3-XM01-M6205

Resolution :

6144 x 6144

Spectrum :

Mono

MORE PIXELS, MORE PERFORMANCE, SAME NANO QUALITY

Features :

Part Number : G3-XM01-M6205
Resolution : 6144 x 6144
Spectrum : Mono
Interface : CoaXPress
Pixel Size : 4.5 µm
Max Frame Rate : 43 fps
Total Pixels ~ 37,7 MP
bit depth : 8 bit, 10 bit
Operating Temperature : 20—60 °C
Dynamic Range : 62 dB

Shutter Type : Global Shutter
Synchronization: Synchronization via external trigger signal or free run
Dimensions (W x H x L) : 32x59x59mm
Mass : 163 gr

Genie Nano-CXP M6200

MORE PIXELS, MORE PERFORMANCE, SAME NANO QUALITY

Genie Nano CXP Family Datasheet

Introducing Genie Nano-CXP, a camera designed for full-throttle performance. Genie Nano-CXP builds on Nano's proven, industry leading reputation and leverages a CoaXPress 6Gbps interface to deliver the maximum throughput from leading edge high resolution CMOS image sensors.
