Model :FG-P5G-50S4M-C: 5.0 MP, 120 FPS, Sony IMX547, Mono

Featured Information

Part Number :
FG-P5G-50S4M-C
Resolution :
2448 × 2048
Frame Rate :
120
Product thumb
FG-P5G-50S4M-C: 5.0 MP, 120 FPS, Sony IMX547, Mono
Forge 5GigE

SPECIFICATIONS

  • Part Number :  FG-P5G-50S4M-C
  • Resolution :  2448 × 2048
  • Frame Rate :  120
  • Megapixels :  5
  • Chroma :  Mono
  • Sensor Name :  Sony IMX547
  • Sensor Type :  CMOS
  • Sensor Format :  1/1.8
  • Readout Method :  Global shutter
  • Pixel Size :  2.74

  • User Sets :  2 user configuration sets for custom camera settings

  • Opto-isolated I/O Ports :  1 input, 1 output
  • Part Number :  FG-P5G-50S4M-C
  • Pixel Size :  2.74
  • Power Consumption [Maximum] :  7 W
  • Power Requirements :  Power over Ethernet (PoE), or 12 V nominal (8 - 24 V) via GPIO
  • Readout Method :  Global shutter
  • Resolution :  2448 × 2048
  • Sensor Format :  1/1.8
  • Sensor Name :  Sony IMX547
  • Sensor Type :  CMOS

RECOMMENDED SYSTEM CONFIGURATION

  • CPU :  3.1 GHz or equivalent CPU
  • Hard Drive :  200 MB hard drive space
  • Operating System :  Windows or Linux (32–bit or 64–bit)
  • Port :  5Gigabit Ethernet Port
  • Power Sourcing Equipment :  IEEE802.3af-2003 PoE Interface Card / Injector/ Switch or Camera Power Supply (12 V 1.5 A, 6–pin Hirose)
  • RAM :  2 GB RAM or more
  • Required Accessories :  Lens, Cable, Host Adapter (GigE), Tripod Mount Adapter (ACC-01-0019)

  • Lens Mount :  C-mount
  • ADC :  8-bit, 10-bit, 12-bit
  • Required Accessories :  Lens, Cable, Host Adapter (GigE), Tripod Mount Adapter (ACC-01-0019)
  • Acquisition Modes :  Continuous Single Frame Multi Frame
  • Exposure Range :  6 µs to 30 seconds
  • Flash Memory :  4 MB non-volatile memory
  • Gain Range :  0 db to 48 dB
  • Image Buffer :  500MB
  • Image Processing :  Gamma, lookup table, and sharpness
  • Partial Image Modes :  Pixel binning, decimation, ROI

PHYSICAL

  • ADC :  8-bit, 10-bit, 12-bit
  • Auxiliary Output :  3.3 V, 120 mA maximum
  • Chroma :  Mono
  • Dimensions [W x H x L] :  29 mm × 44 mm × 74 mm
  • Interface :  5GigE PoE
  • Lens Mount :  C-mount
  • Mass :  TBD
  • Megapixels :  5
  • Non-isolated I/O Ports :  1 bi-directional, 1 input
  • Operating Humidity :  20 to 80% (no condensation)

  • Serial Port :  1 (over non-isolated I/O)
  • Storage Humidity :  30 to 95% (no condensation)

COMPLIANCE & CERTIFICATIONS

  • Compliance :  CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099.
  • Machine Vision Standard :  GigE Vision v1.2
  • Warranty :  3 years

Product thumb
FG-P5G-50S4M-C: 5.0 MP, 120 FPS, Sony IMX547, Mono
Forge 5GigE

The Forge is based on an all-new camera platform designed to support a feature and sensor set to easily build robust and powerful systems faster. It offers flexible link speeds as well as the ability to go beyond 5GigE performance and control data transfer to the host. With OEMs in mind, the Forge provides features for easy integration, a seamless upgrade path from 1GigE systems and supports a choice of SDK’s and GigE Vision compliant software packages.
