CMOS LINE SCAN BUILT FOR MAXIMUM THROUGHPUT
CMOS LINE SCAN BUILT FOR MAXIMUM THROUGHPUT
Model :Piranha4 4k, 50/100 kHz
Featured Information
Part number:
P4-CM-04K05D
Resolution :
4096x2
Spectrum :
Mono
Piranha4 4k, 50/100 kHz
CMOS LINE SCAN BUILT FOR MAXIMUM THROUGHPUT
Features :
- Part number: P4-CM-04K05D
- Resolution : 4096x2
- Spectrum : Mono
- Interface : Camera Link
- Pixel Size : 10.56 µm
- Max Line Rate : 100 kHz
- Total Pixels : ~ 4 k
- Bit Depth : 10 bit, 12 bit
- Operating Temperature : 0—65°C
- Responsivity : 65 DN/nJ/cm2 @ 1x gain, 8-bit
- Dynamic Range : 65 dB
- Dimensions (W x H x L) : 62x62x48 mm
Piranha4 4k, 50/100 kHz
CMOS LINE SCAN BUILT FOR MAXIMUM THROUGHPUT
The Piranha4 cameras offer advanced features such as sub-pixel spatial correction, areas of interest (up to 4 at a time) to reduce data processing and simplify cabling, as well as dual-line area mode to double line rate, HDR mode, shading and lens correction. The Piranha4 is built for the real world with features to ease system integration. The advanced GenICam compliant user interface makes it easy to set up and control camera parameters such as exposure control, FFC, white balance, gain, test patterns, diagnostics and more.
