LRAD 450XL
LRAD 450XL
Featured Information
LRAD 450XL :
LRAD 450XL manually operated, long range communication system with dash mounted MP3 control module
LRAD 450XL
PRODUCT INFORMATION
- LRAD 450XL : LRAD 450XL manually operated, long range communication system with dash mounted MP3 control module
OPTIONAL ACCESSORIES
- Wireless Kit : Wireless transmitter, receiver, and headset that allows remote use of LRAD systemsover ranges up to 200 meters
- HD Action Camera : During LRAD operation, record high definition, date/time stamped video and audio with this compact, rugged digital camera
- Magnetic Mount Kit : Magnetic base and accompanying mounting yoke to secure the LRAD to metallic surfaces including vehicle roofs
- Maxabeam Kit : 12 million candlepower in a lightweight, mounted searchlight that illuminates targets up to 3,500 meters away
- Power Supply Module : External AC to DC power supply, 10-220 VAC to 28 VDC
- Power Pack : Portable power pack with internal battery, charger, 24 VDC, 21 AH
- Hitch Mount : Vehicle Mount - attaches to standard trailer hitch receiver (2 in/5.08 cm)
- GPK Mount : Mounts to Objective Gunner Projection Kit (OGPK) for vehicle mounted operations
- Ship Rail Mount : Stainless steel rail mount
- Table Mount : Flat surface mount
ENVIRONMENTAL PERFORMANCE
- Cold/Hot Operating Temperature : MIL-STD-810G, Method 501.5 & 502.5, Procedure II, -33°C to 60°C
- Cold/Hot Storage Temperature : MIL-STD-810G, Method 501.5 & 502.5, Procedure I, -40°C to 70°C
- Operating Humidity : MIL-STD-810G, Method 507.5, Procedure II, Aggravated Cycle
- Rain : MIL-STD-810G, Method 506.5, Procedure I, Blowing Rain
- Salt Fog : MILD-STD-810G, Method 509.5
- Vibration : MIL-STD-810G, Method 514.6, Wheeled Vehicles
- Safety : MIL-STD-1474D
ELECTRICAL REQUIREMENTS
- Power Consumption : Normal power consumption for voice broadcasts is 55 Watts. Normal power consumption for alert tone is 330 Watts.
- Power Input : 12 - 28 VDC
- Electromagnetic Capability (EMC) : FCC Part 15 class A radiated emissions, CE
INCLUDED ACCESSORIES
- Control Module : Remote MP3 control module
- Record on the Fly Mic : Microphone with record and playback feature for immediate playback
- MP3 Auxiliary Cable : Allows connection to any audio device with a headphone jack
- USB Cable : USB cable for downloading files to the MP3 player
- Hearing Protection : Disposable hearing protection
- Normalizer Software : Normalizer software for creating customized audio recordings on a PC
- Tripod Adapter : Allows for mounting on optional tripod
- Hard Case : Watertight, dust proof, rugged enclosure for storage and transport
ACOUSTIC PERFORMANCE
- Maximum Peak Output : 150 dB SPL @ 1 meter, C-weighted
- Maximum Continuous Output : 145 dB SPL @ 1 meter, A-weighted
- Sound Projection : +/- 15° @ 1 kHz / -3 dB
- Communication Ranges : Maximum range up to 1,700 meters in ideal conditions. Operational range up to 500 meters over 88 dB of background noise. Ranges based on contiunous output.
MECHANICAL SPESIFICATIONS
- Dimensions (WxHxD) : 14 x 27 x 11.6 inch (36.8 x 68.6 x 29.5 cm)
- Weight : 36.5 lbs (16.6 kg) without accessories
- Construction : Molded low smoke composite, 6061 aluminum, 316 stainless hardware
The LRAD 450XL utilizes technology developed and patented by Genasys Inc. to provide the audio output of larger acoustic hailers almost twice its size and weight, while delivering the same outstanding vocal clarity inherent in all LRAD systems. The LRAD 450XL broadcasts powerful warning tones to command attention to the highly intelligible voice messages that follow, enabling operators to change behavior and enhance response capabilities with safe, scalable escalation of force. Lightweight and designed for use on tripods or mounted on vessels, vehicles, and Remote Weapon Stations (RWS), the LRAD 450 XL is a hight effective, long range communication system in use around the world for public safety, law enforcement, maritime and defense applications.
