FLIR M300C
Marine high definition camera with active gyro-stabilization
FLIR M300C
Marine high definition camera with active gyro-stabilization
Featured Information
Lines of Resolution :
Up to 1920 x 1080 @ 30fps
Minimum Illumination :
0.1 lux (ICR off, slow shutter off, high sensitivity off) / 0.006 lux (ICR on, slow shutter off, high sensitivity off)
Visible Detector Type :
1/2.8” CMOS
FLIR M300C
Marine high definition camera with active gyro-stabilization
VISIBLE CAMERA
- Lines of Resolution : Up to 1920 x 1080 @ 30fps
- Minimum Illumination : 0.1 lux (ICR off, slow shutter off, high sensitivity off) / 0.006 lux (ICR on, slow shutter off, high sensitivity off)
- Visible Detector Type : 1/2.8” CMOS
- Visible E-Zoom : 12x
- Visible Field of View : Optical 63.7° x 35.8° WFOV to 2.3° x 1.29° NFOV
- Visible Focal Length : 129 mm to 4.3 mm
- Zoom : 30× Optical Zoom
- Pan-Tilt Adjustment Range : 360° Continuous Pan, ± 90° Tilt
- Power Consumption : 41 W (typical) 56 W (max)
- Wind : 100 knots (115.2 MPH)
SYSTEM SPECIFICATIONS
- Analog Video Connector Types : BNC
- Analog Video Output : NTSC/PAL User Settable
- ClearCruise IR Analytics : Yes, with Raymarine Axiom
- Current : Peak 10.0 A
- Firefighter Mode : No
- Gyro Stabilized : Yes
- HD-SDI Lossless Video Output : Yes
- Network Video Output : Two, Independent H.264/MJPEG Network Video Streams
- ONVIF Conformance : Profile S
- Operating Voltage Range : -10% to +30% of Nominal Supply Range
ENVIRONMENTAL
- Automatic Window Defrost : Standard at Power-Up
- EMI : IEC60945
- Lightning Protection : Near Strike at 2kV
- Operating Temperature Range : -13°F to +131°F (-25°C to +55°C)
- Salt Mist : IEC60945
- Sand & Dust Ingress : Mil-Std-810E or IP6X
- Shock : 15g vertical, 9g horizontal
- Storage Temperature Range : -22°F to +158°F (-30°C to +70°C)
- Vibration : IEC60945
- Water Ingress : IPX6 (heavy seas, power jets of water)
PHYSICAL
- Size : Camera: 8.7” (222mm) x 12.9” (328mm) / Camera with Top-Down Riser: 10.0” (254mm) x 14.4” (366mm)
- Weight : Camera: 13.9lbs (6.3kg) / Camera with Top-Down Riser: 14.9lbs (6.8kg)
FLIR M300C
Marine high definition camera with active gyro-stabilization
Combining a high-performance visible marine camera with long-range optical zoom capability, the M300C offers positive target identification for law enforcement, commercial, and recreational applications. Advanced gyro-stabilization provides steady imaging in rough sea conditions and allows the M300C to monitor targets or hazards over long distances continuously. Exceptional low light performance from the M300C gives captains enhanced awareness once the sun dips below the horizon.
