Blackfly GigE
Blackfly GigE
Model :BFLY-PGE-23S6C-C: 2.3 MP, 41 FPS, Sony IMX249, Color
Featured Information
Part Number :
BFLY-PGE-23S6C-C
Resolution :
1920 × 1200
Frame Rate :
41
BFLY-PGE-23S6C-C: 2.3 MP, 41 FPS, Sony IMX249, Color
Blackfly GigE
SPECIFICATIONS
- Part Number : BFLY-PGE-23S6C-C
- Resolution : 1920 × 1200
- Frame Rate : 41
- Megapixels : 2.3
- Chroma : Color
- Sensor Name : Sony IMX249
- Sensor Type : CMOS
- Sensor Format : 1/1.2
- Readout Method : Global shutter
- Pixel Size : 5.86
- Trigger Modes : Standard, bulb, overlapped, multi-shot
- User Sets : 2 user configuration sets for custom camera settings
PHYSICAL
- ADC : 10 bit, 12 bit
- Auxiliary Output : 3.3 V, 120 mA maximum
- Chroma : Color
- Dimensions [W x H x L] : 29 mm × 29 mm × 30 mm
- Interface : GigE PoE
- Lens Mount : C-mount
- Mass : 36 grams
- Megapixels : 2.3
- Operating Humidity : 20 to 80% (no condensation)
- Operating Temperature : 0° to 45°C
- Storage Temperature : -30° to 60°C
COMPLIANCE & CERTIFICATIONS
- Compliance : CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099.
- Machine Vision Standard : GigE Vision v1.2
- Warranty : 3 years
- Lens Mount : C-mount
- ADC : 10 bit, 12 bit
- Required Accessories : Lens, Cable, Host Adapter (GigE), Tripod Mount Adapter (ACC-01-0003)
- Exposure Range : 0.019 ms to 32 seconds
- Flash Memory : 512 KB non-volatile memory
- Frame Rate : 41
- Gain Range : 0 dB to 29.9 dB
- Image Buffer : 16MB
- Image Processing : Gamma, lookup table, hue, saturation, and sharpness
- Partial Image Modes : Pixel binning, decimation, ROI
PERFORMANCE
- Absolute Sensitivity Threshold (y) : 23.15
- Dynamic Range dB : 67.37
- Power Consumption : 2,5 W
- Quantum Efficiency Blue : 60,25 (460nm)
- Quantum Efficiency Green 59,7 (530nm)
- Quantum Efficiency Red : 37,91 (625nm)
- Saturation Capacity (e-) : 32291
- Temporal Dark Noise (e-) : 6.90
- Opto-isolated I/O Ports : 1 input, 1 output
- Part Number : BFLY-PGE-23S6C-C
- Pixel Size : 5.86
- Power Requirements : 12 V nominal (5 - 16 V) via GPIO interface
- Readout Method : Global shutter
- Resolution : 1920 × 1200
- Sensor Format : 1/1.2
- Sensor Name : Sony IMX249
- Sensor Type : CMOS
- Storage Humidity : 20 to 95% (no condensation)
RECOMMENDED SYSTEM CONFIGURATION
- CPU : 3.1 GHz or equivalent
- Hard Drive : 200 MB hard drive space
- Operating System : Windows or Linux (32-bit or 64-bit)
- Port : Gigabit Ethernet
- Power Sourcing Equipment : PoE Interface Card / Injector/ Switch or Camera Power Supply (12v 1.5A, 6-pin Hirose)
- RAM : 2 GB RAM or more
- Required Accessories : Lens, Cable, Host Adapter (GigE), Tripod Mount Adapter (ACC-01-0003)
BFLY-PGE-23S6C-C: 2.3 MP, 41 FPS, Sony IMX249, Color
Blackfly GigE
The Blackfly® camera line combines Sony CCD, Aptina, e2v, and Sharp sensors with a host of unique features. For FLIR area scan cameras with the latest sensors and most advanced feature sets, please refer to our Blackfly S and Oryx camera families.
