Firefly DL
On-Camera Deep Learning
Firefly DL
On-Camera Deep Learning
Model :FFY-U3-16S2C-C-DL: 1.6 MP, 60 FPS, Sony IMX296, Color
Featured Information
Part Number :
FFY-U3-16S2C-C-DL
Resolution :
1440x1080
Frame Rate :
60
FFY-U3-16S2C-C-DL: 1.6 MP, 60 FPS, Sony IMX296, Color
On-Camera Deep Learning
SPECIFICATIONS
- Part Number : FFY-U3-16S2C-C-DL
- Resolution : 1440x1080
- Frame Rate : 60
- Megapixels : 1.6
- Chroma : Color
- Sensor Name : Sony IMX296
- Sensor Type : CMOS
- Sensor Format : 1/2.9
- Readout Method : Global shutter
- Pixel Size : 3.45
- User Sets : 2 user configuration sets for custom camera settings
PHYSICAL
- ADC : 10-bit
- Auxiliary Output : 3.3 V, 120 mA maximum
- Chroma : Color
- Dimensions [W x H x L] : 27 mm x 27 mm x 14.5 mm
- Interface : USB 3.1 Gen 1
- Lens Mount : C-mount
- Mass : 20 g
- Megapixels : 1.6
- Non-isolated I/O Ports : 4 bi-directional
- Operating Humidity : 20% to 80% (no condensation)
- Storage Humidity : 20% to 95% (no condensation)
- Storage Temperature : -30°C to 60°C (ambient)
COMPLIANCE & CERTIFICATIONS
- Compliance : CE, FCC, KCC, RoHS, REACH. The ECCN for this product is: EAR099
- Machine Vision Standard : USB3 Vision v1.0
- Warranty : 3 years
- Lens Mount : C-mount
- ADC : 10-bit
- Acquisition Modes : Single Frame Multi Frame Continuous
- Exposure Range : 29.0 µs to 30.0 S
- Flash Memory : 24 MB non-volatile memory
- Frame Rate : 60
- Gain Range : 0.0 to 48.0 dB
- Image Buffer : 32MB
- Image Processing : Gamma, lookup table, denoise, and sharpness
- Partial Image Modes : ROI
PERFORMANCE
- Absolute Sensitivity Threshold (y) : 9.54
- Dynamic Range dB : 65.61
- Power Consumption : 2,2 W
- Quantum Efficiency Blue : 47 (470 deniz mili)
- Quantum Efficiency Green : 57 (525 deniz mili)
- Quantum Efficiency Red : 44 (630 deniz mili)
- Saturation Capacity (e-) : 10408
- Temporal Dark Noise (e-) : 4.95
- Operating Temperature : 0°C to 85°C (case)
- Part Number : FFY-U3-16S2C-C-DL
- Pixel Size : 3.45
- Power Requirements : 5 V via USB 3.1 interface
- Readout Method : Global shutter
- Resolution : 1440 x 1080
- Sensor Format : 1/2.9
- Sensor Name : Sony IMX296
- Sensor Type : CMOS
- Serial Port : 1 (over non-isolated I/O)
RECOMMENDED SYSTEM CONFIGURATION
- CPU : 3.1 GHz or equivalent CPU
- Hard Drive : 200 MB hard drive space
- Operating System : Windows or Linux (32–bit or 64–bit)
- Port : USB 3 Port
- RAM : 4 GB RAM or more
FFY-U3-16S2C-C-DL: 1.6 MP, 60 FPS, Sony IMX296, Color
On-Camera Deep Learning
Deep learning is a powerful tool for system designers to quickly automate complex and subjective decision making and deliver higher quality products and improved productivity. Deploy your trained neural network to the FLIR Firefly DL with Neuro technology and reduce system cost and complexity by making decisions on-camera without host PC. With its very small size, low weight and power consumption, the Firefly DL camera is ideal for embedding into mobile, desktop, and handheld systems.
