Blackfly S USB3

Blackfly S USB3

Model :BFS-U3-17S7M-C: 1.7 MP, 196 FPS, Sony IMX425, Mono

Featured Information

Part Number :

BFS-U3-17S7M-C

Resolution :

1600x1100

Frame Rate :

196

BFS-U3-17S7M-C: 1.7 MP, 196 FPS, Sony IMX425, Mono

Blackfly S USB3

SPECIFICATIONS

Part Number : BFS-U3-17S7M-C
Resolution : 1600x1100
Frame Rate : 196
Megapixels : 1.7
Chroma : Mono
Sensor Name : Sony IMX425
Sensor Type : CMOS
Sensor Format : 1.1
Readout Method : Global shutter
Pixel Size : 9

Partial Image Modes : Pixel binning, decimation, ROI
User Sets : 2 user configuration sets for custom camera settings

PHYSICAL

ADC : 12-bit, 10-bit
Auxiliary Output : 3.3 V, 120 mA maximum
Chroma : Mono
Dimensions [W x H x L] : 29 mm × 29 mm × 39 mm
Interface : USB 3.1 Gen 1
Lens Mount : C-mount
Mass : 53 grams
Megapixels : 1.7
Non-isolated I/O Ports : 1 bi-directional, 1 input
Operating Humidity : 20 to 80% (no condensation)

Sensor Type : CMOS
Storage Humidity : 30 to 95% (no condensation)
Storage Temperature : -30° to 60°C

COMPLIANCE & CERTIFICATIONS

Compliance : CE, FCC, KCC, RoHS. The ECCN for this product is: EAR099.
Warranty : 3 years

Lens Mount : C-mount
ADC : 12-bit, 10-bit
Required Accessories : Lens, Cable, Host Adapter (USB 3.1 Gen 1), Tripod Mount Adapter (ACC-01-0016)
Acquisition Modes : Single Frame Multi Frame Continuous
Exposure Range : 9 µs to 30 seconds
Flash Memory : 6 MB non-volatile memory
Frame Rate : 196
Gain Range : 0 dB to 47 dB
Image Buffer : 240MB
Image Processing : Gamma, lookup table, and sharpness

PERFORMANCE

Absolute Sensitivity Threshold (y) : 7,26 (HCG) / 33,52 (LCG)
Dynamic Range dB : 71,53 (HCG) / 72,46 (LCG)
Quantum Efficiency : 72 (HCG) / 70 (LCG) @525 nm
Saturation Capacity (e-) : 19557 (HCG) / 98654 (LCG)
Temporal Dark Noise (e-) : 4,69 (HCG) / 22,99 (LCG)

Operating Temperature : 0° to 50°C
Opto-isolated I/O Ports : 1 input, 1 output
Part Number : BFS-U3-17S7M-C
Pixel Size : 9
Power Consumption [Maximum] : 4,2 W
Power Requirements : 8-24 V via GPIO or 5 V via USB3
Readout Method : Global shutter
Resolution : 1600x1100
Sensor Format : 1.1
Sensor Name : Sony IMX425

RECOMMENDED SYSTEM CONFIGURATION

CPU : 3.1 GHz or equivalent CPU
Hard Drive : 200 MB hard drive space
Operating System : Windows or Linux (32–bit or 64–bit)
Port : USB 3 Port
RAM : 2 GB RAM or more
Required Accessories : Lens, Cable, Host Adapter (USB 3.1 Gen 1), Tripod Mount Adapter (ACC-01-0016)

BFS-U3-17S7M-C: 1.7 MP, 196 FPS, Sony IMX425, Mono

Blackfly S USB3

The Blackfly® S leverages the industry’s most advanced sensors in an ice-cube form factor. It is packed with powerful features enabling you to easily produce the exact images you need and accelerate your application development. This includes both automatic and precise manual control over image capture and on-camera pre-processing. The Blackfly S is available in GigE, USB3, cased, and board-level versions.
