FLIR Elara FB-Series O
Thermal Bullet Camera
FLIR Elara FB-Series O
Thermal Bullet Camera
Model :FLIR FB-349-O, 49 ° FOV, 17 µm
Featured Information
Detector Type :
Long-Life, Uncooled VOx Microbolometer
Dimensions (L x W x H) :
285 x 96 x 94 mm/11.1 x 3.8 x 3.7 With sunshield and fully extended mounting arm
Effective Resolution :
76,800 pixels
FLIR FB-349-O, 49 ° FOV, 17 µm
Thermal Bullet Camera
GENERAL
- Detector Type : Long-Life, Uncooled VOx Microbolometer
- Dimensions (L x W x H) : 285 x 96 x 94 mm/11.1 x 3.8 x 3.7 With sunshield and fully extended mounting arm
- Effective Resolution : 76,800 pixels
- Focus Range : Athermalized, focus-free
- Input Voltage : 12 VDC 24VAC PoE
- Power Consumption : 12 VDC: 17 W (maximum with heaters) 24VAC : 13 VA (maximum with heaters) 24VDC : 13 W (maximum with heaters) PoE: 13 W
SYSTEM INTEGRATION
- Ethernet : 10/100 Mbps
- External Analytics Compatible : Yes
- Network APIs : Nexus SDK for comprehensive system control and integration; Nexus CGI for http command interfaces; ONVIF Profile S
- Supported Protocols : IPV4, HTTP, Bonjour, UPnP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP
VIDEO & RECORDING
- Composite Video NTSC or PAL : Hybrid system with IP & analog video
- Digital Video Compression : Two independent channels of H.264 and MJPEG
- Streaming Resolution PAL/NTSC : Native: 320x256
ENVIRONMENTAL
- Humidity : 10%-90% relative humidity
- IP Rating (dust & water ingress) : IP66
- Operating Temperature Range : -40°C to 50°C
- Regulatory : FCC Part 15 (Subpart B, Class A), CE marked, EN55032, EN55024, RoHS, WEEE
- Storage Temperature Range : -20°C to 70°C
THERMAL CAMERA
- Image Uniformity Optimization : Automatic Flat Field Correction (FFC) - Thermal and Temporal triggers
- Pixel Pitch : 17u
- Thermal AGC Region of Interest [ROI] : Default, Presets and User Defined for optimal image quality of subjects of interest
- Thermal Image Settings : Auto AGC, Dynamic Detail Enhancement (DDE), Brightness, Sharpness, Contrast
VISIBLE CAMERA
- Array Format : 320 × 240
- Field of view (FOV) : 49°
- f-number : F1.3
- Focal Length : 6.8mm
- Sensitivity : <50mK @ 25c F# 1.0
- Spectral Range : 8 µm to 14 µm
- Video Frame Rate : NTSC: 30 Hz PAL: 25 Hz
FLIR FB-349-O, 49 ° FOV, 17 µm
Thermal Bullet Camera
The compact FLIR Elara™ FB-Series O thermal security camera delivers industry-leading thermal imaging for perimeter and wide area protection around the clock. The camera also offers "plug-and-play" compatibility with external video analytics and major VMS suppliers, including FLIR United VMS, for additional functionality and a flawless user experience.
