FLIR Scout TKx
Thermal Imaging Monocular
FLIR Scout TKx
Thermal Imaging Monocular
Featured Information
Drop Test Rating :
2 m
Operating Temperature :
-4°F to 104°F (-20°C to 40°C)
Battery Life (Operating) :
7 Hours
FLIR Scout TKx
Thermal Imaging Monocular
SPECIFICATIONS :
- Drop Test Rating : 2 m
- Operating Temperature : -4°F to 104°F (-20°C to 40°C)
- Battery Life (Operating) : 7 Hours
- Detect Man (1.8m x 0.5m) : 91 m
- Field of view (FOV) : 20° × 16°
- Detector Type : 160 × 120 VOx Microbolometer
- Image Processing : FLIR Proprietary Digital Detail Enhancement™
- Rating : IP-67, Submersible
- Storage Temperature : -40°F to 140°F (-40°C to 60°C)
- Battery Type : Internal Li-Ion Cell
- Color Palettes : Black Hot / White Hot / InstAlert™ / Rainbow / Iron / Lava / Color Wheel/ Graded Fire 1&2
- Package Includes : Handheld Thermal Camera,Neck Lanyard, USB-C Cable, Lens Cap
- Shutter : Yes
- Size (L x W x H) : 6.0" × 2" × 2"
- Warranty : 2 years standard, 3 years with product registration
- Waveband : 7.5–13.5 µm
- Weight [incl lens] : 6 oz (170 g)
- Start Up Time : <5 seconds
- Image Download : USB-C
- Brightness Button : Brightness (toggle up<>down)
- Built-in Display : 640 × 480 LCD Display
- Image Capture : Short press for Image capture, long press for Video capture
- On-Screen Symbology : Standard
- Palette Button : Short press to toggle thru LUT's
- Power Button : On / Off
- Splash Screen : Generic
- Video Refresh Rate : 9Hz
he FLIR Scout TKx is a pocket-sized thermal vision monocular that can help you clearly see people, objects, and animals in total darkness more than 90 meters (100 yards) away. This versatile thermal imager features a simple, user-friendly design and can capture both images and record video. With the Scout TKx, it’s easy to survey large areas and see heat signatures in low-light conditions or outside at night—making it an ideal choice for observing wildlife, home security, or public safety.
