FLIR Scout TKx

Thermal Imaging Monocular
FLIR Scout TKx
Thermal Imaging Monocular

Featured Information

Drop Test Rating :
2 m
Operating Temperature :
-4°F to 104°F (-20°C to 40°C)
Battery Life (Operating) :
7 Hours
Product thumb
FLIR Scout TKx
Thermal Imaging Monocular

SPECIFICATIONS :

  • Drop Test Rating :  2 m
  • Operating Temperature :  -4°F to 104°F (-20°C to 40°C)
  • Battery Life (Operating) :  7 Hours
  • Detect Man (1.8m x 0.5m) :  91 m
  • Field of view (FOV) :   20° × 16°
  • Detector Type :  160 × 120 VOx Microbolometer
  • Image Processing :  FLIR Proprietary Digital Detail Enhancement™
  • Rating :  IP-67, Submersible
  • Storage Temperature :  -40°F to 140°F (-40°C to 60°C)
  • Battery Type :  Internal Li-Ion Cell

  • Color Palettes :  Black Hot / White Hot / InstAlert™ / Rainbow / Iron / Lava / Color Wheel/ Graded Fire 1&2
  • Package Includes :  Handheld Thermal Camera,Neck Lanyard, USB-C Cable, Lens Cap
  • Shutter :  Yes
  • Size (L x W x H) :   6.0" × 2" × 2"
  • Warranty :   2 years standard, 3 years with product registration
  • Waveband :   7.5–13.5 µm
  • Weight [incl lens] :   6 oz (170 g)

  • Start Up Time :  <5 seconds
  • Image Download :  USB-C
  • Brightness Button :  Brightness (toggle up<>down)
  • Built-in Display :   640 × 480 LCD Display
  • Image Capture :  Short press for Image capture, long press for Video capture
  • On-Screen Symbology :   Standard
  • Palette Button :  Short press to toggle thru LUT's
  • Power Button :  On / Off
  • Splash Screen :   Generic
  • Video Refresh Rate :  9Hz

Product thumb
FLIR Scout TKx
Thermal Imaging Monocular

he FLIR Scout TKx is a pocket-sized thermal vision monocular that can help you clearly see people, objects, and animals in total darkness more than 90 meters (100 yards) away. This versatile thermal imager features a simple, user-friendly design and can capture both images and record video. With the Scout TKx, it’s easy to survey large areas and see heat signatures in low-light conditions or outside at night—making it an ideal choice for observing wildlife, home security, or public safety.
