Piranha4 Multispectral
Piranha4 Multispectral
Model :Piranha4 Multispektral RGB+NIR 2k, 70 kHz

Featured Information

Part number :
P4-CC-02K07N
Resolution :
2048x4
Spectrum :
Color, NIR
Product thumb
Piranha4 Multispektral RGB+NIR 2k, 70 kHz
Piranha4 Multispectral

Features :

  • Part number :  P4-CC-02K07N
  • Resolution :  2048x4
  • Spectrum :  Color, NIR
  • Interface :  Camera Link
  • Pixel Size :  14.08 µm
  • Max Line Rate :  70 kHz
  • Total Pixels :  ~ 2 k
  • Bit Depth :  8 bit, 10 bit
  • Operating Temperature :  0—65 °C
  • Responsivity :  700 (R), 800 (G), 600 (B), 300 (NIR) DN/(nj/cm2) @ 1x gain, 12-bit

  • Dynamic Range :  65 dB
  • Dimensions (W x H x L) :  62 x 62 x 48 mm

Product thumb
Piranha4 Multispektral RGB+NIR 2k, 70 kHz
Piranha4 Multispectral

Piranha4's wafer level filters provide clear spectral channel separation. The High speed quadlinear CMOS gives you four spectrally independent channels, exposure control per channel, subpixel spatial and parallax correction, and multiple AOI/ROIs for output/calibration.
